aFe F-250/F-350 2017-2026 Black No-Muffler Axle-Back

No-muffler black-tip axle-back details

aFe 49-43116NM-B This Apollo GT axle-back replaces the original muffler and rear exhaust with a no-muffler assembly, 3.5–4-inch mandrel-bent 409 stainless tubing and ONE black 6-inch-outlet stainless tip. The selected system uses factory-style connections and hangers with 100% MIG-welded construction.

Key Features

• Selected NM-B configuration: NO muffler and ONE black clamp-on tip.
• 3.5–4-inch mandrel-bent 409 stainless tubing.
• 100% MIG-welded construction.
• Black stainless tip with riveted aFe POWER logo plate.
• Original resonator-pipe connection and rubber isolation mounts retained.
• No-cut/no-modification installation described for the listed factory layout.
• Three selected exhaust sections and three supplied band clamps.

Fitment

2017–2026 Ford F-250/F-350 Super Duty GAS V8 applications, with engine years explicitly separated by the selected manual: 6.2L for 2017–2022, 6.8L for 2023–2026 and 7.3L for 2020–2026. Match the original resonator-pipe connection, hangers and cab/bed layout. Current manufacturer lists Regular Cab/Long Bed 142-inch wheelbase, Super Cab/Short Bed 148-inch, Super Cab/Long Bed 164-inch, Crew Cab/Short Bed 160-inch and Crew Cab/Long Bed 176-inch. Existing broad F-250/F-350 rows remain and extend to the current model range; proper Super Duty model rows are also shown. Exact selected SD Wheel named-trim support is through 2025, not 2026. Its 4WD-only positive rows apply to F-250 Platinum throughout 2017–2025; to F-250 King Ranch, Lariat and XLT in 2023–2025; and to F-350 King Ranch and Platinum in 2023–2025. These restrictions remain applicable even though the fitment search cannot encode drivetrain in a trim name. No diesel application is established.

Verify 49-43116NM-B against the actual engine, flange, hangers and mounting locations and applicable emissions requirements before ordering.

Specifications

What's Included

• 1 x 05-144947: Muffler-delete pipe — selected no-muffler assembly.
• 1 x 05-144945: Over-axle pipe.
• 1 x 05-144946: Tailpipe.
• 1 x 49T40601-B12: BLACK stainless tip; 4-inch inlet x 6-inch outlet x 12-inch length.
• 1 x 05-41055: 3-inch band clamp, as printed.
• 2 x 05-41171: 3.5-inch band clamps.

THREE selected exhaust sections: muffler-delete pipe 05-144947, over-axle pipe 05-144945 and tailpipe 05-144946. ONE BLACK stainless clamp-on tip 49T40601-B12 is listed as 4-inch inlet, 6-inch outlet and 12-inch length. Supplied bands are ONE 3-inch 05-41055 and TWO 3.5-inch 05-41171, exactly as printed. The shared manual also lists muffler 05-144944 and polished tip 49T40601-P12 as ALTERNATIVES; neither is an extra in this no-muffler/black-tip selection. Reuse the factory rubber isolation mounts. No intake filter, intake coupler, replacement resonator, converter, sensor or valve motor is itemized.

About aFe Power

aFe Power develops application-specific intake, filtration, exhaust, cooling, tuning, suspension, drivetrain, and truck-performance components supported by product testing and documented installation requirements.

Related Parts

• Manufacturer product specifications for 49-43116NM-B
• Exact illustrated installation manual
• Shop the complete aFe Power collection

FAQ

THREE selected exhaust sections: muffler-delete pipe 05-144947, over-axle pipe 05-144945 and tailpipe 05-144946. ONE BLACK stainless clamp-on tip 49T40601-B12 is listed as 4-inch inlet, 6-inch outlet and 12-inch length. Supplied bands are ONE 3-inch 05-41055 and TWO 3.5-inch 05-41171, exactly as printed. The shared manual also lists muffler 05-144944 and polished tip 49T40601-P12 as ALTERNATIVES; neither is an extra in this no-muffler/black-tip selection. Reuse the factory rubber isolation mounts. No intake filter, intake coupler, replacement resonator, converter, sensor or valve motor is itemized.

2017–2026 Ford F-250/F-350 Super Duty GAS V8 applications, with engine years explicitly separated by the selected manual: 6.2L for 2017–2022, 6.8L for 2023–2026 and 7.3L for 2020–2026. Match the original resonator-pipe connection, hangers and cab/bed layout. Current manufacturer lists Regular Cab/Long Bed 142-inch wheelbase, Super Cab/Short Bed 148-inch, Super Cab/Long Bed 164-inch, Crew Cab/Short Bed 160-inch and Crew Cab/Long Bed 176-inch. Existing broad F-250/F-350 rows remain and extend to the current model range; proper Super Duty model rows are also shown. Exact selected SD Wheel named-trim support is through 2025, not 2026. Its 4WD-only positive rows apply to F-250 Platinum throughout 2017–2025; to F-250 King Ranch, Lariat and XLT in 2023–2025; and to F-350 King Ranch and Platinum in 2023–2025. These restrictions remain applicable even though the fitment search cannot encode drivetrain in a trim name. No diesel application is established.

No. The manual covers muffled/unmuffled and black/polished alternatives. This selection uses delete pipe 05-144947 and BLACK tip 49T40601-B12 only. Muffler 05-144944 and polished tip 49T40601-P12 are not extra supplied parts.

Remove the original muffler assembly and tailpipe UP TO THE FACTORY RESONATOR PIPE. Retain that resonator connection and reuse the original rubber isolation mounts. The selected procedure does not call for cutting, battery disconnection or sensor/valve work.

Install the delete pipe with the supplied 3-inch band, then the over-axle pipe with one 3.5-inch band, then the tailpipe with the second 3.5-inch band. Engage the original isolation mounts. Fit and position the selected black tip before final alignment and tightening.

Align the assembly and check surrounding clearances. Tighten evenly from FRONT to REAR. Band clamps require 40–45 ft-lb. No separate numeric tip-fastener torque is supplied; do not borrow a value from another tip or kit.

Re-tighten ALL clamps and hardware after 50–100 miles. At installation, start the vehicle and locate and repair leaks before lowering it.

Current exact manufacturer states no CARB EO number is required. This does not waive local sound requirements or authorize changes to unrelated emissions equipment. No actual dyno or airflow chart is linked for this exact selection and no measured drone result is supplied. Generic page fields for an included filter or coupler do not add intake components to the exhaust bill.

Installation Instructions

Verify aFe 49-43116NM-B.

1. Read BOTH pages and all FOURTEEN steps of the selected September 2026 manual, including the shared bill, selected-parts diagram and installed photograph. Confirm the exact gas engine year and cab/bed layout. Inspect shipping condition, allow the exhaust to cool, wear eye/hand protection and support the vehicle at its specified jack-stand positions. Independently support the original exhaust; leave new joints loose for alignment.
2. Remove the original MUFFLER ASSEMBLY AND TAILPIPE up to the FACTORY RESONATOR PIPE. The manufacturer describes a no-cut/no-modification installation for the listed layout, and this selected manual does not specify a cut. Do not remove the factory resonator or substitute a catalytic-converter connection procedure.
3. Install selected delete pipe 05-144947 using the supplied 3-inch band clamp, engaging its hangers in the original rubber isolation mounts. Do not install the alternative muffler shown in the shared drawing.
4. Fit over-axle pipe 05-144945 with ONE supplied 3.5-inch band. Fit tailpipe 05-144946 with the SECOND 3.5-inch band and engage its hanger in the original isolation mount. Install the selected BLACK tip and adjust its position.
5. Align all sections and check safe clearance to wires, hoses, brake lines, body and tires. Starting at the FRONT, evenly tighten clamps and fasteners. The selected manual gives 40–45 ft-lb for BAND CLAMPS; it gives no separate numeric torque for the tip fastener.
6. Start the vehicle, check and repair any leaks, then lower it safely. Re-tighten ALL clamps and hardware after 50–100 miles. No battery disconnection, sensor transfer, valve-motor replacement or coding procedure is specified.

Current exact manufacturer states no CARB EO number is required. This does not waive local sound requirements or authorize changes to unrelated emissions equipment. No actual dyno or airflow chart is linked for this exact selection and no measured drone result is supplied. Generic page fields for an included filter or coupler do not add intake components to the exhaust bill.
