SKU: 100-7744 | UPC: 672036049645
ARP 2017+ Honda Civic Type R / Si Wheel Stud Kit
The ARP 2017+ Honda Civic Type R / Si Wheel Stud Kit (100-7744) replaces factory wheel studs on 2017-2021 Honda Civic Type R (FK8) and Civic Si hatchback models. Forged from 8740 chromoly steel these studs resist fatigue and stretching under high loads from wide wheels lowered suspensions and track abuse. Install them for dependable wheel retention during spirited driving.
Key Features
- 8740 Chromoly Steel Construction: Delivers 200000 PSI tensile strength to handle extreme torque and impacts better than OEM steel
- Rolled Threads: Increases fatigue strength by up to 1000 percent over cut threads preventing thread galling and strip-out
- Precision Knurl Diameter (0.595 in): Ensures secure press fit into hub bores without distortion or loosening over time
- M12x1.5 Thread with 1.650 in Thread Length: Matches OEM specs for direct replacement on 5x114.3 lug pattern wheels
- 2.720 in Overall Length and Hex Head: Provides clearance for OEM and aftermarket lug nuts with easy service access
Product Notes
- Kit includes 20 studs to outfit all four wheels completely
- Apply ARP Ultra-Torque assembly lube to threads for accurate torque and corrosion protection
- Ships in compact padded box measuring 5.25 x 3 x 1 inches
Installation Notes
- Professional installation recommended.
- Remove old studs with slide hammer or press inspect hub bores for damage and clean thoroughly
- Press new studs straight using ARP press tool or arbor press torque lug nuts to 80 ft-lbs in star pattern
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2017-2021 | Honda | Civic | Type R (FK8) |
| 2017-2021 | Honda | Civic | Si (Hatchback) |
Why Choose ARP?
- ARP fasteners power professional racing teams in NHRA Formula Drift and endurance series
- Every stud undergoes rigorous testing for tensile fatigue and hardness
- Engineered in the USA with exact tolerances for Honda platforms
Frequently Asked Questions
-
Q: Will this kit fit 2022+ Honda Civic Si models?
A: No ARP 100-7744 fits only 2017-2021 10th generation Civic Type R and Si hatchback use 100-7950 for 2022+ 11th gen Si -
Q: What finish protects these studs from rust?
A: Black oxide coating resists corrosion in wet conditions pair with antiseize lube for wheels exposed to brake dust and road salt -
Q: What warranty covers ARP wheel studs?
A: Limited lifetime warranty against manufacturing defects when installed and torqued correctly contact ARP for claims
Shipping & Handling
- Method: UPS Ground or USPS Priority
- Availability: In stock - ships same or next business day
- Packaging: Secure padded box 5.25 x 3 x 1 inches
- Weight: 1.10 lbs
