SKU: 100-7743 | UPC: 672036651237
ARP 92-02 Mazda RX7 Wheel Stud Kit - 5 Pack
This ARP wheel stud kit contains five replacement studs designed specifically for the 1992-2002 Mazda RX-7. These studs provide reliable wheel retention for street driving and track performance by replacing worn factory studs that can loosen under high loads. Built to handle extreme torque and repeated impacts these studs ensure wheels stay firmly in place during aggressive cornering and acceleration.
Key Features
- 8740 Chromoly Steel Construction: Forged from premium 8740 chrome moly steel and heat treated to 200000 psi tensile strength for durability under racing stresses
- Precise Dimensions: 14mm shank diameter 2.160 inch overall length with M12x1.5 rolled right-hand threads for exact OEM replacement fit
- Knurled Design: Knurling on the smooth shank section allows secure press-fit installation into wheel hubs without slipping
- Rolled Threads: Rolling process creates denser thread grain structure that resists fatigue and stripping far better than cut threads
- 5-Pack Quantity: Perfect for servicing one wheel hub ideal for targeted repairs or maintenance on rotary-powered RX-7s
Product Notes
- Inspect hub bores for wear before installation to ensure proper seating
- Use anti-seize on threads during wheel installation for easy future removal
- Packaged in protective ARP tube to prevent damage during storage and transit
Installation Notes
- Professional installation recommended.
- Press studs into hub using an arbor press or hydraulic press after freezing studs and heating hub slightly for interference fit
- Compatible with OEM lug nuts and aftermarket wheels verify 12x1.5 thread match
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| 1992-2002 | Mazda | RX-7 | All |
| 1993-1995 | Mazda | RX-7 | R1 R2 |
| 1996-2002 | Mazda | RX-7 | Base Spirit R |
Why Choose ARP?
- ARP fasteners secure top racing teams in NHRA Pro Stock and Formula Drift
- Every stud undergoes rigorous testing for consistent strength and reliability
- Precision manufacturing with tight tolerances guarantees perfect fit and function
Frequently Asked Questions
-
Q: Will this kit fit my 1995 Mazda RX-7 R2?
A: Yes ARP 100-7743 fits all 1992-2002 Mazda RX-7 models including R1 R2 and Spirit R variants with FD chassis hubs -
Q: What material are these wheel studs made from?
A: Constructed from 8740 chromoly steel heat treated to 200000 psi with rolled threads for maximum strength and resistance to thread galling -
Q: What is the warranty and installation process?
A: ARP offers a limited lifetime warranty against manufacturing defects. Installation requires pressing into clean hub bores professional tools advised
Shipping & Handling
- Method: UPS Ground or USPS Priority
- Availability: In stock - ships same or next business day
- Packaging: Compact protective tube inside shipping box 6 x 4 x 1 inches
- Weight: 0.4 lbs
