OE-Grade Ceramic Stopping Power for Your Acura Integra and Honda Civic
The Brembo P28048N Prime Ceramic front brake pad delivers factory-matched stopping performance with the added benefit of ceramic compound technology. Engineered as a direct OE equivalent for 1994-2001 Acura Integra and 1994-1995 Honda Civic applications, P28048N pads are designed to Akebono braking system specifications with precise pad geometry, acoustic wear indicators, and anti-squeal shims included in the box. Whether you drive a GS-R, Type R, LS, RS, or Civic Si, P28048N installs without modification and restores like-new braking feel.
Key Features
- Brembo P28048N Prime Ceramic compound for reduced noise, vibration, and dust versus conventional metallic pads
- OE-equivalent fitment engineered to Akebono braking system specs for 1994-2001 Acura Integra and 1994-1995 Honda Civic
- Acoustic wear indicator alerts you before pad material is depleted
- Anti-squeal shim included to eliminate brake noise and brake judder
- Low dust formulation keeps wheels visibly cleaner between cleanings
- FMSI D617 7493 cross-reference for fitment verification
- Pad dimensions: 129mm wide x 55mm tall x 17mm thick
- Drop-in replacement with no modifications required
Fitment
| Year Range | Make | Model | Trim |
|---|---|---|---|
| 1994-2001 | Acura | Integra | GS-R |
| 1994-2001 | Acura | Integra | LS |
| 1994-2001 | Acura | Integra | RS |
| 1994-2001 | Acura | Integra | GS |
| 1994-2001 | Acura | Integra | Special Edition |
| 1994-2001 | Acura | Integra | Type R |
| 1994-1995 | Honda | Civic | EX |
| 1994-1995 | Honda | Civic | LX |
| 1994-1995 | Honda | Civic | Si |
Specifications
| Detail | Value |
|---|---|
| Part Number | P28048N |
| UPC | 8020584086742 |
| Compound | NAO Ceramic (Prime Ceramic) |
| Position | Front |
| Braking System | Akebono |
| FMSI Number | D617 7493 |
| WVA Number | 23566, 23567, 23568 |
| Pad Width | 129 mm |
| Pad Height | 55 mm |
| Pad Thickness | 17 mm |
| Wear Indicator | Acoustic |
| Quantity | 1 set (front axle) |
What's Included
- 1x Brembo P28048N Prime Ceramic front brake pad set (both sides)
- Anti-squeal shims
Frequently Asked Questions
What vehicles does the Brembo P28048N fit?P28048N fits 1994-2001 Acura Integra in GS-R, LS, RS, GS, Special Edition, and Type R trim levels, as well as 1994-1995 Honda Civic EX, LX, and Si. Always confirm your brake caliper brand (Akebono) before ordering.
Is P28048N a ceramic or metallic brake pad?P28048N uses Brembo's NAO Ceramic compound, branded as Prime Ceramic. It is a non-asbestos organic ceramic formulation designed for low noise, low dust, and smooth everyday stopping.
Will P28048N work on my Acura Integra Type R?Yes. P28048N is confirmed to fit the 1994-2001 Acura Integra Type R (DC2) alongside the GS-R, LS, RS, GS, and Special Edition variants.
How does Brembo P28048N compare to the standard P28048 pad?The suffix N denotes the NAO Ceramic formulation. The standard P28048 uses Brembo's Prime Low-Metallic compound, which offers slightly more aggressive bite. P28048N ceramic pads trade a small amount of cold-bite for noticeably less brake dust, less rotor wear, and quieter operation.
Do I need to bed in Brembo ceramic brake pads?Yes. A proper break-in procedure is recommended. Perform 6 to 10 moderate stops from 30 mph to 10 mph without coming to a full stop, allowing the pads to cool between each stop. This transfers an even layer of pad material onto the rotor surface for optimal performance and longevity.
Are these pads compatible with cross-drilled or slotted rotors?Brembo P28048N pads are designed to work with standard smooth-face rotors. They are compatible with cross-drilled and slotted rotors as well, though ceramic compound pads generally pair best with plain or UV-coated rotors for daily driving use.
What is the FMSI number for P28048N?The FMSI number for Brembo P28048N is D617 7493. This cross-reference number can be used to verify pad compatibility across aftermarket brake manufacturers and catalogs.
How long will Brembo P28048N pads last on an Acura Integra?Pad life depends heavily on driving style and conditions. Under typical street driving conditions, ceramic brake pads on a lightweight Integra or Civic can last 40,000 to 60,000 miles. Aggressive driving or mountainous terrain will reduce pad life significantly.
Do Brembo P28048N pads come with anti-squeal shims?Yes. Anti-squeal shims are included with P28048N to help dampen vibration and prevent brake squeal. Install the shims between the pad backing plate and caliper piston during installation.
Installation Instructions
- Safely raise the vehicle and support it on jack stands. Remove the front wheels.
- Remove the brake caliper mounting bolts and slide the caliper off the rotor. Support the caliper with a wire hook to avoid stressing the brake hose.
- Remove the old brake pads and retaining clips from the caliper bracket.
- Clean the caliper bracket contact surfaces with a wire brush and apply brake caliper lubricant to the slide pins and pad contact areas only.
- Use a brake piston tool or C-clamp to compress the caliper piston fully back into the bore to make room for the new thicker pads.
- Install the new P28048N pads into the caliper bracket. Attach the included anti-squeal shims to the backing plate of each pad.
- Reinstall the caliper over the pads and torque the caliper mounting bolts to factory specification (typically 28 ft-lbs for Integra/Civic).
- Reinstall the wheels and torque the lug nuts to spec.
- Pump the brake pedal repeatedly until firm pedal feel is restored before moving the vehicle.
- Check brake fluid level and top off if necessary. Perform a proper bed-in procedure before aggressive braking.
