Put 1000 Horsepower Through The Front Axles Without Snapping A Bar
The factory 27 spline center bar is the first thing to fail once a built RB26 starts putting real power to the ground. The DSS RA8010X5-V2 Level 5 front axle replaces that weak point with a 36 spline aerospace grade bar and a billet CV setup rated to handle up to 1000 horsepower, so the driveline stops being the limiting factor on your Skyline.
Key Features
- Upgraded from the factory 27 spline bar to a 36 spline aerospace grade center bar
- Billet inner CV with a splined plug that mates directly to the differential
- Billet bolt-on inner mounts to the factory drive flange on the opposite end
- Outer CV built from a proprietary high strength material with factory ABS tone rings retained
- Rated to handle up to 1000 horsepower for street, drag, and road course use
- Direct OEM style fitment, no cutting or modification required to install
- Left side (driver side) application, part number RA8010X5-V2
Fitment Table
| Year Range | Make | Model | Trim |
|---|---|---|---|
| 1989-2002 | Nissan | Skyline | GT-R |
Specifications
| Detail | Value |
|---|---|
| Brand | Driveshaft Shop (DSS) |
| MPN | RA8010X5-V2 |
| UPC | N/A |
| Position | Front, Left (Driver Side) |
| Spline Count | 36 (upgraded from factory 27 spline) |
| Power Rating | Up to 1000HP |
| CV Type | Billet inner CV, proprietary material outer CV with ABS tone ring |
| Warranty | 1 Year |
What's Included
- One DSS RA8010X5-V2 Level 5 front axle, left side
About Driveshaft Shop
Driveshaft Shop has built axles and driveline components for drag racing, road racing, and rally competition for decades. Their Level 5 line is engineered around larger spline center bars and billet CV components to survive sustained high horsepower abuse where factory axles fail.
FAQ
What is the RA8010X5-V2?The RA8010X5-V2 is a DSS Level 5 front left axle for the 1989-2002 Nissan Skyline GT-R, upgraded to a 36 spline center bar and billet CV components rated for up to 1000 horsepower.
Which side does the RA8010X5-V2 fit?The RA8010X5-V2 is the left side, driver side front axle. The matching right side axle is sold under a separate part number.
Does this axle require any modification to install?No, the RA8010X5-V2 is designed for OEM style, direct bolt-in fitment with no cutting or modification required.
What horsepower can this axle handle?The RA8010X5-V2 is rated to handle up to 1000 horsepower, making it suitable for heavily built RB26 platforms.
Does this axle retain the factory ABS function?Yes, the outer CV on this axle has the ABS tone ring installed so factory ABS operation is retained.
Does this fit both the R32 and R34 Skyline GT-R?Yes, this axle fits the 1989-2002 Nissan Skyline GT-R across the R32, R33, and R34 chassis generations.
What is upgraded compared to the factory front axle?The factory 27 spline center bar is replaced with a 36 spline aerospace grade bar, and the CV joints are upgraded to billet and proprietary high strength materials.
What is the warranty on this axle?The RA8010X5-V2 carries a 1 year manufacturer warranty from Driveshaft Shop.
Install Instructions
- Raise and support the vehicle safely, then remove the front wheel on the driver side.
- Remove the factory front left axle from the hub and differential following factory service procedures.
- Install the RA8010X5-V2 into the differential, engaging the billet inner CV spline.
- Bolt the outer CV to the front hub assembly using factory hardware and torque specifications.
- Reinstall the wheel and torque lug nuts to factory specification.
- Check CV boot clearance and driveline angle through full steering lock before road testing.
