Flow-Formed F14 Drag Fitment for the Ford F-150
Forgestar F27879589P25 is a 17x9.5 F14 Drag wheel with a 6x135 bolt pattern, +25 mm offset, 6.23-inch backspacing, and Silver Machined finish. Forgestar's fitment guide identifies this configuration for 2015-2026 Ford F-150 applications, subject to brake, tire, suspension, and payload clearance checks.
Key Features
- Flow-formed one-piece construction balances strength and reduced rotating mass
- 17x9.5 size with 6x135 bolt pattern for the listed Ford F-150 application
- +25 mm offset and 6.23-inch backspacing
- Deep-concave F14 Drag profile in Silver Machined finish
- 87.1 mm center bore and 1,520 lb published wheel load rating
Fitment
| Year | Make | Model | Fitment notes |
|---|---|---|---|
| 2015-2026 | Ford | F-150 | Verify brake package, tire size, suspension height, hub fit, and load requirements |
Specifications
| Detail | Value |
|---|---|
| Manufacturer part number | F27879589P25 |
| Wheel size | 17x9.5 |
| Bolt pattern | 6x135 |
| Offset | +25 mm |
| Backspacing | 6.23 in |
| Center bore | 87.1 mm |
| Construction | Flow formed, one piece |
| Profile | Deep concave |
| Finish | Silver Machined |
| Load rating | 1,520 lb per wheel |
| UPC | 190300619740 |
| Quantity | One wheel |
What's Included
- One Forgestar F14 Drag wheel identified by F27879589P25
- Center cap when supplied by Forgestar
- Tire, TPMS sensor, valve stem, lug nuts, and mounting service are not included unless separately listed
About Forgestar
Forgestar produces flow-formed and forged performance wheels for street, track, and drag applications. Its vehicle fitment guides combine wheel dimensions with model-specific brake and chassis requirements. The F27879589P25 configuration is cataloged as a specific F14 Drag fitment, not a generic wheel size.
Related Parts
- Forgestar F14 Drag 17x9.5 Satin Black wheel — the verified active alternate finish with the same 6x135, +25 mm, and 6.23-inch dimensional configuration.
FAQ
What is the F27879589P25?It is a Silver Machined Forgestar F14 Drag flow-formed wheel in the exact dimensions shown in the specifications table.
Is this wheel sold individually?Yes. The listed quantity is one wheel.
Will it fit every Ford F-150 from the listed years?No single wheel fitment is automatic. Confirm brakes, hub dimensions, suspension, tire size, fender clearance, and payload for the exact truck.
What lug nuts are required?Use lug hardware with the correct thread, seat profile, shank dimensions, and torque specification for the truck and wheel.
Is a TPMS sensor included?No. Transfer or install a compatible sensor separately.
What does flow formed mean?The barrel is formed under pressure after casting to improve material properties and reduce weight compared with a conventional gravity-cast barrel.
Can it be used for towing?Only when the wheel, tire, and complete vehicle setup meet or exceed every axle and payload requirement.
Should a test fit be performed?Yes. Test the front and rear positions before tire mounting to confirm caliper, suspension, and body clearance.
Installation Instructions
- Confirm the truck and wheel requirements match Forgestar F27879589P25 before mounting a tire.
- Test fit the bare wheel at the intended axle position and rotate it to check caliper, suspension, and body clearance.
- Install a compatible valve stem or TPMS sensor and mount a tire with the correct load index and dimensions.
- Balance the assembly using wheel-safe equipment and inspect hub and lug-seat contact.
- Install the wheel with the correct lug hardware and torque it in a star pattern to the vehicle specification.
- Recheck lug torque after the first 50 to 100 miles and inspect for any contact under full steering and suspension travel.
