The World's First Concave Monoblock Beadlock Wheel for Your F-150
The Forgestar F28170089P42 F14 Beadlock wheel brings genuine drag strip engineering to your 2004 to 2025 Ford F-150. This 17x10 wheel in a 6x135 bolt pattern features the world's first concave monoblock beadlock construction, with the spoke design integrated directly into the beadlock ring for a look and function that no other wheel on the market can match. A rotary formed flow formed barrel keeps weight down while the deep concave profile is re-engineered for high offset applications, so you get the aggressive stance without sacrificing strength.
Key Features
- World's first concave monoblock beadlock construction, F28170089P42
- Spoke design integrated into the beadlock ring for a seamless look
- Dual bead knurling for secure tire retention under hard launches
- Rotary formed flow formed 6061 aluminum barrel for reduced unsprung weight
- Deep concave profile re-engineered specifically for high offset fitments
- Clears most big brake kits front and rear
- Drilled to cone seat lug specs, conical or tapered lug nuts required
Vehicle Fitment
| Year Range | Make | Model |
|---|---|---|
| 2004-2025 | Ford | F-150 |
Fits 2004-2025 Ford F-150 trucks equipped with the 5.0L Coyote V8, EcoBoost, 4.6L V8, 5.4L V8, and supercharged or turbocharged applications. A 3/8 inch spacer is needed to clear 4WD hardware up front. This wheel also shares the 6x135 bolt pattern used on select Lincoln Navigator Black Label 4WD models.
Specifications
| Detail | Value |
|---|---|
| Part Number | F28170089P42 |
| Brand | Forgestar |
| Wheel Size | 17x10 |
| Bolt Pattern | 6x135 |
| Offset | +42mm |
| Backspacing | 7.15 inches |
| Hub Bore | 87.1mm |
| Finish | Gloss Black |
| Material | Flow Formed Aluminum |
| Construction | Monoblock Beadlock |
| Weight | 26 lbs |
| Warranty | Lifetime Structural, 1 Year Limited on Finish |
| UPC | Not assigned by manufacturer at time of listing |
What's Included
- (1) Forgestar F28170089P42 F14 Beadlock 17x10 Gloss Black wheel
- Beadlock ring and hardware kit as pictured
About Forgestar
Forgestar builds lightweight flow formed monoblock wheels for performance, drag, and off-road applications. The F14 Beadlock lineup was engineered as the first concave monoblock beadlock wheel on the market, combining true beadlock function with a spoke design built into the ring itself. Every Forgestar wheel is backed by a lifetime structural warranty to the original retail purchaser.
Related Parts on Our Site
FAQ
What is the F28170089P42?The F28170089P42 is a Forgestar F14 Beadlock wheel measuring 17x10 with a 6x135 bolt pattern, +42mm offset, and 7.15 inches of backspacing in a gloss black finish. It fits 2004-2025 Ford F-150 trucks and features true monoblock beadlock construction.
Do I need a spacer to run this wheel on a 4WD F-150?Yes. A 3/8 inch spacer is required to clear 4WD hardware up front on applicable F-150 models.
What lug nuts do I need for this wheel?This wheel is drilled to cone seat specifications, so conical or tapered lug nuts are required for proper seating.
Is this a functional beadlock or a cosmetic beadlock ring?The F14 Beadlock features genuine dual bead knurling and a functional beadlock ring design intended for drag strip use, not a purely cosmetic appearance.
Will this wheel clear big brake kits?Yes. The F14 Beadlock is engineered to clear most big brake kits thanks to its deep concave profile re-engineered for high offset fitments.
What is the hub bore on the F28170089P42?This wheel has an 87.1mm hub bore.
How much does the F28170089P42 weigh?The wheel weighs approximately 26 pounds.
What warranty comes with Forgestar wheels?Forgestar backs this wheel with a lifetime structural warranty to the original retail purchaser and a one year limited warranty against finish defects under normal use.
Install Instructions
- Confirm your vehicle's bolt pattern matches 6x135 before ordering.
- Raise and safely support the vehicle on a lift or jack stands.
- Remove the factory or existing wheel and inspect hub and lug studs.
- Install a 3/8 inch spacer if running on a 4WD-equipped F-150 to clear front hardware.
- Mount the wheel and hand-thread cone seat lug nuts to avoid cross-threading.
- Torque lug nuts to the vehicle manufacturer's specification in a star pattern.
- Lower the vehicle and re-torque lug nuts after the first 50 to 100 miles of driving.
