H&R Trak+ 3mm DR Wheel Spacer — 5/112 Bolt Pattern, 66.5mm Center Bore, 14x1.5 Thread, Black
H&R part 06556650SW is a Trak+ 3mm DR wheel spacer for the 5/112 bolt pattern with a 66.5mm center bore and 14x1.5mm thread, finished in black. H&R Trak+ spacers push the wheels outward for a flush, aggressive stance while remaining hubcentric for even load distribution and lateral support, just like the factory hub.
Key Features
- 3mm thickness, DR (bolt-on) style
- 5/112 bolt pattern, 66.5mm center bore
- 14x1.5mm thread pitch
- Hubcentric design for even load distribution
- Constructed from a proprietary alloy stronger than 6061-T6 billet aluminum
Fitment
| Application | Details |
|---|---|
| Universal (bolt pattern specific) | Fits vehicles with 5/112 bolt pattern, 66.5mm center bore, 14x1.5 thread |
Specifications
| Detail | Value |
|---|---|
| Manufacturer part number | 06556650SW |
| Thickness | 3mm |
| Bolt pattern | 5x112 |
| Center bore | 66.5mm |
| Thread | 14x1.5 |
| Finish | Black |
What's Included
- 1 H&R Trak+ 3mm DR wheel spacer
About H&R
H&R Special Springs specializes in suspension and wheel fitment components, including sport springs, coilovers, and Trak+ wheel spacers engineered for precise fitment and performance.
FAQ
What bolt pattern does this spacer fit?This spacer fits a 5x112 bolt pattern with a 66.5mm center bore.
What thread size does this spacer use?This spacer uses a 14x1.5mm thread.
Is this spacer vehicle specific?This spacer fits any vehicle matching the 5/112 bolt pattern, 66.5mm center bore, and 14x1.5 thread specification; confirm these specs match your vehicle before ordering.
What does DR mean for this spacer?DR refers to a bolt-on spacer style that uses the vehicle's existing lug bolts or studs without adding extended studs.
Is this spacer hubcentric?Yes, this spacer is hubcentric, featuring a full contact hub for even load force distribution and lateral support.
Is professional installation recommended?Yes, wheel spacer installation should be performed by someone experienced with proper torque specifications and wheel fitment safety.
Will this spacer affect my vehicle's wheel offset?Yes, adding a spacer increases the effective wheel offset outward; confirm fender clearance before installation.
What material is this spacer made from?This spacer is made from a proprietary alloy with higher tensile strength than 6061-T6 billet aluminum.
Installation Instructions
- Support the vehicle safely and remove the wheel per standard procedure.
- Install the spacer onto the hub, ensuring proper hubcentric seating.
- Reinstall the wheel over the spacer and torque the lug bolts to the vehicle manufacturer's specification.
- Recheck lug torque after a short test drive.
