Click to zoom in
SKU: 71008-AZ007 | UPC: 4957266265307
HKS 93-96 RX7 TT SSQV4 BOV Kit
The HKS SSQV4 BOV Kit delivers precise control over excess boost pressure for 1993-1996 Mazda RX-7 Twin Turbo models (FD3S). This complete assembly includes the SSQV4 valve, RX7-specific adapter flange, gasket, and hardware for direct bolt-on replacement of the stock pipe. It safeguards turbos from compressor surge while producing a sharp, audible release that enhances driving feedback.
Key Features
- Dual Sequential Valves: Small valve operates at idle and low boost for quiet performance, large valve engages at high boost for full discharge without compressor surge
- Pilot Actuator Design: Handles pressures up to 2.0 kgf/cm² (29 psi) reliably, preventing valve flutter under high-boost conditions
- Adjustable Preload: Turn the adjustment screw to fine-tune valve opening for specific boost levels and driving preferences
- Direct Fit Kit: Includes dedicated RX7 intercooler pipe flange and straight piping to replace stock setup seamlessly
- High-Flow Capacity: Oversized discharge port supports increased airflow from upgraded turbos and intercoolers
Product Notes
- Kit requires no cutting or fabrication on compatible RX7 models
- Regular inspection of O-rings and fittings ensures long-term reliability
- Packaged securely to prevent damage during transit
Installation Notes
- Professional installation recommended.
- Bolt directly to factory intercooler outlet location using provided hardware.
- Compatible with stock or aftermarket boost piping configurations.
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| 1993-1996 | Mazda | RX-7 | Twin Turbo (FD3S) |
| 1993-1995 | Mazda | RX-7 | Turbo (USDM R1) |
Why Choose HKS?
- Proven track record in JDM motorsports and tuning since 1973
- Manufactured with tight tolerances for consistent performance
- Engineered for rotary engines like the RX7 13B-REW
Frequently Asked Questions
-
Q: Will this kit fit 1993-1995 US-spec RX-7 Twin Turbo?
A: Yes, it bolts directly to the FD3S intercooler piping on 1993-1996 RX7 TT models including USDM versions without modifications. -
Q: What materials are used in the SSQV4 BOV?
A: Die-cast aluminum body and housing with durable anodized finish for corrosion resistance and lightweight strength at 650g per valve. -
Q: What is the HKS warranty on this BOV kit?
A: HKS offers a limited lifetime warranty against manufacturing defects when installed and maintained properly.
Shipping & Handling
- Method: UPS Ground or FedEx
- Availability: In stock - ships same or next business day
- Packaging: Protective cardboard box measuring 12in x 9in x 5in
- Weight: 4.4 lbs (2kg)
