Sharpen the Stance of Your 2025+ BMW M5 Sedan G90 with H&R Trak+ 13mm Black DR Wheel Spacers
The H&R HRS265455664SW Trak+ 13mm Black DR Wheel Spacers are precision-engineered for the 2025+ BMW M5 Sedan (G90), adding 13mm of outward wheel offset per side to maximize the factory fender-to-wheel clearance and deliver a sharper, more aggressive visual stance. The black anodized finish pairs seamlessly with the M5 G90's performance-oriented styling. Machined from H&R's proprietary high-strength alloy with greater tensile strength than standard 6061-T6 billet aluminum, the HRS265455664SW uses the DR (Dual Retention) design for a secure, hub-centric installation on the G90's unique 5/132 bolt pattern. Hub-centric 66.5mm bore ensures a vibration-free fit at all speeds. Thread: 14x1.5. Sold as a pair with a limited lifetime warranty.
Key Features
- 13mm wheel offset increase per side for the 2025+ BMW M5 Sedan G90
- Black anodized finish for a premium, stealth appearance
- DR (Dual Retention) design for secure hub and wheel retention
- HRS265455664SW machined from H&R proprietary alloy exceeding 6061-T6 tensile strength
- Hub-centric 66.5mm bore eliminates vibration at all speeds
- Bolt Pattern: 5/132 | Center Bore: 66.5mm | Thread: 14x1.5
- Sold as a pair (2 spacers)
- Limited lifetime warranty
Fitment
| Year Range | Make | Model | Trim |
|---|---|---|---|
| 2025+ | BMW | M5 | Sedan |
Specifications
| Detail | Value |
|---|---|
| Part Number | 265455664SW |
| Brand | H&R Special Springs |
| Type | Trak+ DR Wheel Spacer |
| Finish | Black Anodized |
| Thickness | 13mm per side |
| Bolt Pattern | 5/132 |
| Center Bore | 66.5mm |
| Thread | 14x1.5 |
| Quantity | Pair (2) |
| Warranty | Limited Lifetime |
What Is Included
- 2x H&R HRS265455664SW Trak+ 13mm Black DR wheel spacers
- Installation hardware
Frequently Asked Questions
What is the total track width increase from the HRS265455664SW on the BMW M5 G90?Each HRS265455664SW adds 13mm per side for a total track width increase of 26mm (approximately 1.02 inches) across one axle when both spacers are installed.
Are these spacers specifically designed for the 2025+ BMW M5 G90?Yes. The HRS265455664SW is engineered for the 2025+ BMW M5 Sedan (G90) specifically, using the G90's unique 5/132 bolt pattern, 66.5mm center bore, and 14x1.5 thread pitch.
Are H&R DR spacers hub-centric for the BMW M5 G90?Yes. The HRS265455664SW is machined to a 66.5mm center bore matching the BMW M5 G90 hub specification for a precise, vibration-free hub-centric fit.
What does DR (Dual Retention) mean?DR means the spacer uses independent retention hardware on both the inboard face (securing the spacer to the hub) and the outboard face (securing the wheel to the spacer). Both retention points are mechanically independent, preventing relative movement at either interface.
Does the SW suffix indicate a black finish?Yes. SW stands for Schwarz, the German word for black. The spacer features a black anodized finish for a premium, stealth appearance at the wheel face.
Do H&R DR spacers require re-torquing after installation?Yes. Re-torque all wheel fasteners after the first 50 to 100 miles of driving to confirm all hardware remains at the specified torque value.
How many sets are needed to equip all four corners of the BMW M5 G90?Each set contains 2 spacers and covers one axle. Two sets are required for all four wheels of the vehicle.
Will these spacers affect my BMW M5 G90 factory warranty?Adding wheel spacers is a modification. Whether it affects a specific warranty claim is at the discretion of BMW and the dealership. Consult your BMW dealer for guidance specific to your situation.
Installation Instructions
- Safely raise and support the vehicle on jack stands at all four corners.
- Remove wheels and thoroughly clean hub face and wheel mating surfaces.
- Mount the HRS265455664SW spacer onto the hub and secure using the inboard retention hardware. Torque to the factory specification in a star pattern.
- Mount the wheel onto the spacer's outboard face and thread on the outboard lug hardware.
- Torque to the vehicle manufacturer's wheel specification in a star pattern.
- Lower the vehicle and perform a final torque check at ride height.
- Re-torque after 50 to 100 miles of driving.
- Verify clearance at full steering lock and full suspension compression before normal driving.
