Improve Your 2022-2026 Hyundai Ioniq 5 Stance with H&R Trak+ 15mm Black DRM Wheel Adaptors
The H&R HRS30656730SW Trak+ 15mm Black DRM Wheel Adaptors are precision-machined for the 2022-2026 Hyundai Ioniq 5, adding 15mm of outward wheel offset per side to bring the factory or aftermarket wheels closer to flush with the fenders. The black anodized finish provides a clean, stealth look that complements the Ioniq 5's bold exterior design. Machined from H&R's proprietary high-strength alloy with greater tensile strength than standard 6061-T6 billet aluminum, the HRS30656730SW uses the DRM (Dual Retention Method) to independently secure the adaptor to the hub and the wheel to the adaptor. Hub-centric 67.1mm bore ensures a vibration-free fit. Bolt pattern: 5/114.3. Thread: 12x1.5. Sold as a pair with a limited lifetime warranty.
Key Features
- 15mm wheel offset increase per side for the 2022-2026 Hyundai Ioniq 5
- Black anodized finish for a stealth, modern look
- DRM (Dual Retention Method) dual-locking design for independent hub and wheel retention
- HRS30656730SW machined from H&R proprietary alloy exceeding 6061-T6 tensile strength
- Hub-centric 67.1mm bore eliminates vibration at all speeds
- Bolt Pattern: 5/114.3 | Center Bore: 67.1mm | Thread: 12x1.5
- Sold as a pair (2 adaptors)
- Limited lifetime warranty
Fitment
| Year Range | Make | Model | Trim |
|---|---|---|---|
| 2022-2026 | Hyundai | Ioniq 5 | SE Standard Range |
| 2022-2026 | Hyundai | Ioniq 5 | SE |
| 2022-2026 | Hyundai | Ioniq 5 | SEL |
| 2022-2026 | Hyundai | Ioniq 5 | Limited |
| 2022-2026 | Hyundai | Ioniq 5 | XRT |
| 2024-2026 | Hyundai | Ioniq 5 | N |
Specifications
| Detail | Value |
|---|---|
| Part Number | 30656730SW |
| Brand | H&R Special Springs |
| Type | Trak+ DRM Wheel Adaptor |
| Finish | Black Anodized |
| Thickness | 15mm per side |
| Bolt Pattern | 5/114.3 |
| Center Bore | 67.1mm |
| Thread | 12x1.5 |
| Quantity | Pair (2) |
| Warranty | Limited Lifetime |
What Is Included
- 2x H&R HRS30656730SW Trak+ 15mm Black DRM wheel adaptors
- Installation hardware (lug bolts/nuts)
Frequently Asked Questions
What is the total track width increase from the HRS30656730SW on the Ioniq 5?Each HRS30656730SW adds 15mm per side, for a total track width increase of 30mm (approximately 1.18 inches) across one axle when both adaptors are installed.
What is the difference between the HRS30656730SW and the HRS30656730?Both adaptors add 15mm per side and fit the same 2022-2026 Hyundai Ioniq 5 with the same 5/114.3 bolt pattern, 67.1mm center bore, and 12x1.5 thread. The HRS30656730SW features a black anodized finish, while the HRS30656730 has a natural silver finish.
Are these adaptors hub-centric for the Hyundai Ioniq 5?Yes. The HRS30656730SW is machined to a 67.1mm center bore matching the Ioniq 5 hub specification, providing a precise, vibration-free hub-centric fit.
What does DRM (Dual Retention Method) mean?DRM means the adaptor is independently secured to the hub using inboard lug hardware and the wheel is independently secured to the adaptor using outboard lug hardware. These two systems are mechanically separate, preventing relative movement at either interface.
Do H&R DRM adaptors require re-torquing after installation?Yes. Re-torque all lug hardware after the first 50 to 100 miles of driving to ensure all fasteners remain at the specified torque value.
Do I need two sets for all four corners of the Ioniq 5?Yes. Each set of HRS30656730SW includes 2 adaptors covering one axle. Two sets are needed for all four wheels.
Will 15mm adaptors clear the factory brake calipers on the Ioniq 5?Yes. The 15mm DRM design uses its own lug hardware rather than the factory studs, which provides clearance from the factory brake calipers on the Ioniq 5. Always verify clearance after installation.
Is the Ioniq 5 N compatible with these adaptors?Yes. The 2024-2026 Hyundai Ioniq 5 N shares the same 5/114.3 bolt pattern, 67.1mm center bore, and 12x1.5 thread pitch, making the HRS30656730SW a direct fit.
Installation Instructions
- Safely raise and support the vehicle on jack stands at all four corners.
- Remove wheels and thoroughly clean hub face and wheel mating surfaces.
- Mount the HRS30656730SW adaptor onto the hub using the inboard lug hardware. Torque to the factory specification in a star pattern.
- Mount the wheel onto the adaptor's outboard face using the included outboard lug hardware.
- Torque outboard lug hardware to the vehicle manufacturer's wheel specification in a star pattern.
- Lower the vehicle and perform a final torque check at ride height.
- Re-torque after 50 to 100 miles of driving.
- Verify clearance at full steering lock and full suspension compression before normal driving.
WARNING: This product can expose you to chemicals including lead and phthalates, which are known to the State of California to cause cancer and reproductive harm. For more information go to www.P65Warnings.ca.gov.
