Push Your 2023-2025 BMW XM G09 Wheels Outward with H&R Trak+ 18mm Black DR Wheel Spacers
The H&R HRS3675664SW Trak+ 18mm Black DR Wheel Spacers are precision-machined for the 2023-2025 BMW XM (G09), adding 18mm of outward wheel offset per side to bring the factory or aftermarket wheels closer to flush with the wide-body fenders. The black anodized finish delivers a stealthy, refined look that complements the XM's bold design. Machined from H&R's proprietary high-strength alloy with greater tensile strength than standard 6061-T6 billet aluminum, the HRS3675664SW uses the DR (Dual Retention) design for a secure, hub-centric installation. Hub-centric 66.5mm bore ensures a vibration-free fit. Bolt pattern: 5/120. Thread: 14x1.25. Sold as a pair with a limited lifetime warranty.
Key Features
- 18mm wheel offset increase per side for the 2023-2025 BMW XM (G09)
- Black anodized finish for a refined, stealth look
- DR (Dual Retention) design for secure hub and wheel retention
- HRS3675664SW machined from H&R proprietary alloy exceeding 6061-T6 tensile strength
- Hub-centric 66.5mm bore eliminates vibration at all speeds
- Bolt Pattern: 5/120 | Center Bore: 66.5mm | Thread: 14x1.25
- Sold as a pair (2 spacers)
- Limited lifetime warranty
Fitment
| Year Range | Make | Model | Trim |
|---|---|---|---|
| 2023-2025 | BMW | XM | XM |
| 2024-2025 | BMW | XM | Label |
| 2024-2025 | BMW | XM | Label Red |
Specifications
| Detail | Value |
|---|---|
| Part Number | 3675664SW |
| Brand | H&R Special Springs |
| Type | Trak+ DR Wheel Spacer |
| Finish | Black Anodized |
| Thickness | 18mm per side |
| Bolt Pattern | 5/120 |
| Center Bore | 66.5mm |
| Thread | 14x1.25 |
| Quantity | Pair (2) |
| Warranty | Limited Lifetime |
What Is Included
- 2x H&R HRS3675664SW Trak+ 18mm Black DR wheel spacers
- Installation hardware
Frequently Asked Questions
What is the total track width increase from the HRS3675664SW on the BMW XM?Each HRS3675664SW adds 18mm per side for a total track width increase of 36mm (approximately 1.42 inches) across one axle when both spacers are installed.
Are these spacers hub-centric for the 2023-2025 BMW XM G09?Yes. The HRS3675664SW is machined to a 66.5mm center bore matching the BMW XM G09 hub specification for a precise, vibration-free, hub-centric fit.
What does DR (Dual Retention) mean on H&R wheel spacers?DR means the spacer uses a dual-point retention system to independently secure the spacer to the hub and the wheel to the spacer, preventing movement at either interface and providing a highly stable installation.
Does the SW suffix mean these have a black finish?Yes. The SW designation indicates a Schwarz (black) anodized finish on the spacer body. This provides a clean, stealth appearance at the wheel face.
Do H&R DR spacers require re-torquing?Yes. Re-torque all wheel fasteners after the first 50 to 100 miles of driving to confirm all hardware remains at the correct torque specification.
How many sets do I need for all four corners of the BMW XM?Each set contains 2 spacers covering one axle. Two sets are needed for all four wheels of the vehicle.
Will 18mm spacers cause any clearance issues on the BMW XM G09?H&R engineers the HRS3675664SW specifically for the BMW XM G09 platform. Always verify clearance at full steering lock and full suspension travel after installation before normal driving.
Are these spacers compatible with aftermarket BMW XM wheels?Yes, provided the aftermarket wheels use the 5/120 bolt pattern and are compatible with the 66.5mm center bore. Confirm all specifications with the wheel manufacturer before purchasing.
Installation Instructions
- Safely raise and support the vehicle on jack stands at all four corners.
- Remove wheels and thoroughly clean hub face and wheel mating surfaces.
- Mount the HRS3675664SW spacer onto the hub. Secure using the inboard retention hardware. Torque to the factory specification in a star pattern.
- Mount the wheel onto the spacer's outboard face and thread on the outboard lug hardware.
- Torque to the vehicle manufacturer's wheel specification in a star pattern.
- Lower the vehicle and perform a final torque check at ride height.
- Re-torque after 50 to 100 miles of driving.
- Verify clearance at full steering lock and full suspension compression before normal driving.
