Go Flush on Your 2023-2026 Honda Civic Type R FL5 with H&R Trak+ 30mm Black DRM Wheel Adaptors
The H&R HRS6075644SW Trak+ 30mm Black DRM Wheel Adaptors push the wheels of your 2023-2026 Honda Civic Type R FL5 outward by 30mm per side, delivering a truly flush, track-ready stance. The black anodized finish adds a stealth look that complements the Type R's aggressive styling. Machined from H&R's proprietary high-strength alloy with greater tensile strength than standard 6061-T6 billet aluminum, the HRS6075644SW uses the DRM (Dual Retention Method) to independently secure the adaptor to the hub and the wheel to the adaptor. Hub-centric 64.1mm bore ensures a vibration-free fit at all speeds. Bolt pattern: 5/120. Thread: 14x1.5. Sold as a pair with a limited lifetime warranty.
Key Features
- 30mm wheel offset increase per side for the 2023-2026 Honda Civic Type R FL5
- Black anodized finish for a stealth, track-inspired look
- DRM (Dual Retention Method) dual-locking system secures adaptor and wheel independently
- HRS6075644SW machined from H&R proprietary alloy exceeding 6061-T6 tensile strength
- Hub-centric 64.1mm bore eliminates vibration at all speeds
- No factory stud trimming required on the FL5 with 30mm adaptors
- Bolt Pattern: 5/120 | Center Bore: 64.1mm | Thread: 14x1.5
- Sold as a pair (2 adaptors)
- Limited lifetime warranty
Fitment
| Year Range | Make | Model | Trim |
|---|---|---|---|
| 2023-2026 | Honda | Civic Type R | Type R |
Specifications
| Detail | Value |
|---|---|
| Part Number | 6075644SW |
| Brand | H&R Special Springs |
| Type | Trak+ DRM Wheel Adaptor |
| Finish | Black Anodized |
| Thickness | 30mm per side |
| Bolt Pattern | 5/120 |
| Center Bore | 64.1mm |
| Thread | 14x1.5 |
| Quantity | Pair (2) |
| Warranty | Limited Lifetime |
What Is Included
- 2x H&R HRS6075644SW Trak+ 30mm Black DRM wheel adaptors
- Installation hardware (lug bolts/nuts)
Frequently Asked Questions
What is the total track width increase from the HRS6075644SW?Each HRS6075644SW adds 30mm per side for a total track width increase of 60mm (approximately 2.36 inches) across one axle when both adaptors are installed.
Does the 30mm DRM adaptor require trimming factory studs on the FL5?No. Unlike smaller-thickness spacers on certain Honda applications, the HRS6075644SW 30mm adaptor does not require trimming or shaving of the factory FL5 wheel studs.
What is the difference between the HRS6075644SW and the HRS5075644?The HRS6075644SW adds 30mm per side and features a black anodized finish. The HRS5075644 adds 25mm per side with a natural finish. Both fit the 2023-2026 Honda Civic Type R FL5 with the same 5/120 bolt pattern, 64.1mm center bore, and 14x1.5 thread.
Are these adaptors hub-centric for the Honda Civic Type R FL5?Yes. The HRS6075644SW is machined to a 64.1mm center bore, which matches all generations of the Honda Civic Type R, ensuring a vibration-free hub-centric fit on the FL5.
What does the SW suffix mean on H&R wheel adaptors?The SW designation indicates a Schwarz (black) anodized finish on the adaptor body, as opposed to the natural silver finish found on non-SW variants of the same part.
Do I need to re-torque after installing H&R DRM adaptors?Yes. Re-torque all lug hardware to the specified torque value after the first 50 to 100 miles of driving to ensure all fasteners remain properly seated.
How many sets do I need for all four corners of the Civic Type R?Each set of HRS6075644SW includes 2 adaptors covering one axle. Purchase two sets to equip all four wheels of the FL5.
Will 30mm adaptors affect my Honda Civic Type R warranty?Adding wheel adaptors is a modification. Whether it impacts a specific warranty claim is at the discretion of the dealership. Consult your Honda dealer for guidance specific to your situation.
Installation Instructions
- Safely raise and support the vehicle on jack stands at all four corners.
- Remove wheels and thoroughly clean hub face and wheel mating surfaces.
- Mount the HRS6075644SW adaptor onto the hub using the inboard lug hardware. Torque to the factory specification in a star pattern.
- Mount the wheel onto the adaptor's outboard face using the included outboard lug hardware.
- Torque outboard lug hardware to the vehicle manufacturer's wheel specification in a star pattern.
- Lower the vehicle and perform a final torque check at ride height.
- Re-torque after 50 to 100 miles of driving.
- Verify clearance at full steering lock and full suspension compression before normal driving.
