ICON Toyota Rear 9.5in U-Bolt Kit for 1995-2023 Tacoma, 2000-2021 Tundra, 2019-2023 Silverado 1500 & Sierra 1500
ICON rear U-bolt kit delivers reliable axle clamping for Toyota Tacoma, Tundra, Chevrolet Silverado 1500, and GMC Sierra 1500 trucks with leaf spring rear suspensions. Measuring 9.5 inches long, these U-bolts secure stock leaf packs or aftermarket upgrades without modification. Built from high-strength steel with E-coating, they resist corrosion for long-lasting performance on and off road.
Key Features
- Square U-Bolt Design: Provides precise fit and even clamping pressure to prevent leaf spring shift during heavy loads or rough terrain.
- High-Strength Steel Construction: Forged to handle extreme stress from towing, hauling, and off-road abuse without bending or failure.
- E-Coated Finish: Shields against rust and environmental damage, ensuring durability in harsh conditions like mud, salt, and moisture.
- 9.5-Inch Length: Direct replacement for OEM U-bolts, compatible with factory setups or lifted leaf spring packs up to specified heights.
- Complete Kit Contents: Includes 2 U-bolts, 8 grade 8 nuts, and 8 hardened washers for immediate bolt-on installation.
Product Notes
- Verify leaf spring pack thickness before install to confirm 9.5-inch U-bolt suitability.
- Use anti-seize on threads during assembly to ease future maintenance.
- Ships in protective packaging to prevent damage. inspect upon arrival.
Installation Notes
- Professional installation recommended.
- Torque nuts to 120-140 ft-lbs in a star pattern after seating U-bolts fully.
- Compatible with ICON leaf spring kits and OEM hardware. reuse axle saddle if undamaged.
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2019-2023 | Chevrolet | Silverado 1500 | Custom |
| 2019-2023 | Chevrolet | Silverado 1500 | Custom Trail Boss |
| 2019-2023 | Chevrolet | Silverado 1500 | High Country |
| 2019-2023 | Chevrolet | Silverado 1500 | LT |
| 2019-2023 | Chevrolet | Silverado 1500 | LT Trail Boss |
| 2019-2023 | Chevrolet | Silverado 1500 | LTZ |
| 2023 | Chevrolet | Silverado 1500 | PPV |
| 2019-2023 | Chevrolet | Silverado 1500 | RST |
| 2019-2021 | Chevrolet | Silverado 1500 | SSV |
| 2019-2023 | Chevrolet | Silverado 1500 | WT |
| 2022-2023 | Chevrolet | Silverado 1500 | ZR2 |
| 2022 | Chevrolet | Silverado 1500 LTD | Custom |
| 2022 | Chevrolet | Silverado 1500 LTD | Custom Trail Boss |
| 2022 | Chevrolet | Silverado 1500 LTD | High Country |
| 2022 | Chevrolet | Silverado 1500 LTD | LT |
| 2022 | Chevrolet | Silverado 1500 LTD | LT Trail Boss |
| 2022 | Chevrolet | Silverado 1500 LTD | LTZ |
| 2022 | Chevrolet | Silverado 1500 LTD | RST |
| 2022 | Chevrolet | Silverado 1500 LTD | SSV |
| 2022 | Chevrolet | Silverado 1500 LTD | WT |
| 2019-2023 | GMC | Sierra 1500 | AT4 |
| 2022-2023 | GMC | Sierra 1500 | AT4X |
| 2019-2021 | GMC | Sierra 1500 | Base |
| 2019-2023 | GMC | Sierra 1500 | Denali |
| 2022-2023 | GMC | Sierra 1500 | Denali Ultimate |
| 2019-2023 | GMC | Sierra 1500 | Elevation |
| 2022-2023 | GMC | Sierra 1500 | Pro |
| 2019-2023 | GMC | Sierra 1500 | SLE |
| 2019-2023 | GMC | Sierra 1500 | SLT |
| 2022 | GMC | Sierra 1500 Limited | AT4 |
| 2022 | GMC | Sierra 1500 Limited | Denali |
| 2022 | GMC | Sierra 1500 Limited | Elevation |
| 2022 | GMC | Sierra 1500 Limited | Pro |
| 2022 | GMC | Sierra 1500 Limited | SLE |
| 2022 | GMC | Sierra 1500 Limited | SLT |
| 1995-2015 | Toyota | Tacoma | Base |
| 1998 | Toyota | Tacoma | DLX |
| 1998-2000,2016-2023 | Toyota | Tacoma | Limited |
| 1998-2015 | Toyota | Tacoma | Pre Runner |
| 2001-2004 | Toyota | Tacoma | S-Runner |
| 2016-2023 | Toyota | Tacoma | SR |
| 1995-2000,2016-2023 | Toyota | Tacoma | SR5 |
| 2021 | Toyota | Tacoma | Trail |
| 2016-2023 | Toyota | Tacoma | TRD Off-Road |
| 2015,2017-2023 | Toyota | Tacoma | TRD Pro |
| 2016-2023 | Toyota | Tacoma | TRD Sport |
| 2005-2013 | Toyota | Tacoma | X-Runner |
| 2014-2021 | Toyota | Tundra | 1794 Edition |
| 2000-2013 | Toyota | Tundra | Base |
| 2000-2021 | Toyota | Tundra | Limited |
| 2021 | Toyota | Tundra | Nightshade |
| 2010-2021 | Toyota | Tundra | Platinum |
| 2014-2021 | Toyota | Tundra | SR |
| 2000-2011,2014-2021 | Toyota | Tundra | SR5 |
| 2021 | Toyota | Tundra | Trail |
| 2015-2017,2019-2021 | Toyota | Tundra | TRD Pro |
Why Choose ICON?
- ICON leads in vehicle dynamics with parts tested on race trucks and daily drivers.
- Every component uses premium materials for strength and longevity under real-world demands.
- Engineered in the USA with CAD precision for exact fitment across applications.
Frequently Asked Questions
-
Q: Does this fit my 2020 Toyota Tacoma TRD Off-Road with stock suspension?
A: Yes, the 9.5-inch U-bolts are direct replacements for 1995-2023 Tacoma models including TRD Off-Road with factory leaf springs. -
Q: What material and finish do the U-bolts have?
A: Made from high-strength alloy steel with black E-coat finish for superior corrosion protection in wet or salted environments. -
Q: What is the torque spec for installation?
A: Tighten grade 8 nuts to 120-140 ft-lbs using a calibrated torque wrench after multiple passes in a crisscross pattern.
Shipping & Handling
- Method: UPS Ground or FedEx Ground
- Availability: In stock - ships same or next business day
- Packaging: Secure foam-wrapped box measuring 11 x 7 x 2.5 inches
- Weight: 4.1 lbs product weight, 4.65 lbs shipping weight
