The Mickey Thompson Classic III wheel, material number 277011, uses product code 226100477 and the exact 17x12 in, 8x170mm configuration shown. Use every listed dimension and the current Mickey Thompson application notes before ordering.
Key Features
- Classic eight-hole one-piece cast-aluminum wheel design
- Polished finish with a smooth outer lip
- Wide 17x12-inch configuration with -58 mm offset
- 3,500-pound maximum load rating per wheel
- Includes the specified screw-on center cap
- Requires 60-degree bulge-acorn cone-seat lug nuts
Fitment
Select by the complete 8x170 wheel specification. Confirm brake, hub, suspension, tire, fender, load, and lug-seat compatibility; bolt pattern alone does not establish vehicle fitment.
| Fitment Basis | Required Verification |
|---|---|
| 17x12 in / 8x170mm | Backspacing, offset, hub bore, brake clearance, load rating, tire clearance, and lug-seat type |
Specifications
| Brand | Mickey Thompson |
|---|---|
| Series | Classic III |
| Manufacturer Part Number | 226100477 |
| Material Number | 277011 |
| Wheel Size | 17x12 in |
| Bolt Pattern | 8x170mm |
| Backspacing | 4.2 in (listed as 4.25 in) |
| Offset | -58 mm |
| Hub Bore | 125.20 mm |
| Maximum Load | 3,500 lb per wheel |
| Approximate Weight | 25 lb |
| Construction | One-piece cast aluminum |
| Finish | Polished aluminum |
| Condition | New |
| UPC | 787025506211 |
What's Included
One Mickey Thompson Classic III wheel and one 250372 screw-on center cap. Tires, TPMS sensors, lug nuts, mounting, and balancing are not included.
Installation Notes
Use 60-degree bulge-acorn cone-seat lug nuts and follow the vehicle and wheel manufacturer's torque sequence. Verify the wheel seats fully on the hub, clears the brakes and suspension, and remains within the vehicle's load requirements. Recheck lug torque after the initial driving interval specified by the installer.
Related Mickey Thompson Products
- Shop Mickey Thompson tires, wheels, and accessories
- Shop aftermarket wheels
- Mickey Thompson Classic III 17x12 polished 8x6.5 wheel
- Mickey Thompson Classic III 17x9 polished 8x6.5 wheel
Frequently Asked Questions
Will 277011 fit my vehicle?
Fitment is not assigned from bolt pattern alone. Confirm the complete specifications and all current Mickey Thompson notes for the exact vehicle and tire package.
Does this listing include a full set?
No. This listing includes one wheel unless the quantity selector states otherwise.
Which lug nuts are required?
Mickey Thompson specifies 60-degree bulge-acorn cone-seat lug nuts for Classic Series wheels and recommends duplex bulge-acorn lug nuts on vehicles with a GVWR of 6,500 pounds or greater.
