Superlift 15-18 Ford F-150 4WD 4.5-6in Lift Kit - Knuckles Component Box

Superlift 9930 Front Knuckle Component Box for 4.5 to 6-Inch Lift Kits on 2015-2018 Ford F-150 4WD

The Superlift 9930 is a front knuckle component box designed as part of the 4.5-inch to 6-inch lift kit system for the 2015-2018 Ford F-150 4WD (excluding Raptor). The 9930 contains CNC-machined ductile iron steering knuckles with lifted spindles, laser-cut front top-mount strut spacers, one-piece front and rear cross members, and associated brackets, providing the core front suspension geometry correction required for the Superlift 4.5-6 inch system. Part number 9930 is a component box that pairs with additional Superlift kit boxes to create a complete lift system. It requires no welding, cutting, or drilling for installation.

Features and Benefits

• CNC-machined ductile iron steering knuckles with black powder coat finish maintain OE alignment specifications after lifting
• Laser-cut front top-mount strut spacers for precision fitment
• One-piece front and rear cross members, laser cut and CNC formed for maximum strength
• CNC-machined billet aluminum driveshaft spacer included
• Front differential skid plate for added underbody protection
• Sway bar relocation brackets maintain proper sway bar function after lift
• Differential relocation brackets for proper axle and differential positioning
• Brake line relocation brackets prevent over-extension during suspension travel
• Eccentric cam-bolts for alignment adjustment after installation
• Accommodates factory 18-inch and larger wheels
• Designed for up to 35-inch tires
• Direct bolt-on, no welding, cutting, or drilling required
• Backed by Superlift Limited Lifetime Warranty

Fitment

Specifications

What Is Included

• CNC-machined ductile iron front steering knuckles (driver and passenger side)
• Laser-cut front top-mount strut spacers (pair)
• One-piece front and rear cross members
• CNC-machined billet aluminum driveshaft spacer
• Front differential skid plate
• Sway bar relocation brackets
• Differential relocation brackets
• Brake line relocation brackets
• Eccentric cam-bolts
• All hardware and fasteners

Frequently Asked Questions

Is the 9930 a complete lift kit for my 2015-2018 Ford F-150 4WD?
No. The 9930 is a front component box that contains the front knuckle and bracket hardware for a Superlift 4.5-6 inch system. It must be combined with additional Superlift kit boxes (such as the rear component box and shocks) to create a complete system.

Does the 9930 fit the 2015-2018 Ford F-150 Raptor?
No. The 9930 is not compatible with Raptor models or Single Cab body styles. It fits SuperCab and SuperCrew configurations in King Ranch, Lariat, Limited, Platinum, SSV, XL, and XLT trims.

What wheel size is required when using the 9930 component box?
The 9930 is designed for 18-inch and larger wheels. It is not compatible with 17-inch factory wheels.

Will installing the 9930 void my Ford F-150 factory warranty?
Under the Magnuson-Moss Warranty Act, a dealer must specifically prove that an aftermarket component caused a given failure in order to deny a warranty claim. Simply having a lift kit installed does not permit the dealer to void your entire powertrain warranty. Consult your dealer for specific warranty questions.

Does the 9930 require welding or drilling during installation?
No. The 9930 is a fully bolt-on component box. No welding, cutting, or drilling is required.

Does my 2015-2018 F-150 have a two-piece rear driveshaft?
Some 2015-2018 F-150 models equipped with certain cab and bed configurations have a two-piece rear driveshaft. If your truck has a two-piece rear driveshaft, you will need to order the additional Superlift kit box 9935 for carrier bearing shims.

What is the maximum tire size I can run after installing the 9930-based system?
Superlift rates this system for up to 35-inch x 12.5-inch tires with appropriate wheel offset.

Is a professional alignment required after installing the 9930?
Yes. A professional four-wheel alignment is required. The eccentric cam-bolts included with the 9930 allow for proper caster and camber correction during the alignment process.

Installation Instructions

1. Safely lift the vehicle and support at the frame on jack stands. Remove both front wheels.
2. Disconnect front sway bar end links from the axle.
3. Remove the front strut assembly from the vehicle.
4. Install the laser-cut top-mount strut spacers onto the factory strut towers using included hardware.
5. Remove the factory front steering knuckles from the lower control arm and hub assembly.
6. Install the Superlift CNC-machined ductile iron replacement knuckles, ensuring all ball joint and hub bolts are torqued to specification.
7. Install the CNC-machined driveshaft spacer on the front driveshaft as directed in the instructions.
8. Install the one-piece front and rear cross members per the instructions.
9. Install differential relocation brackets to reposition the front differential at the new lift height.
10. Install sway bar relocation brackets and brake line relocation brackets.
11. Install the front differential skid plate and eccentric cam-bolts.
12. Reinstall front wheels, lower the vehicle, and torque all fasteners to specification at ride height.
13. Have a professional four-wheel alignment performed immediately after installation.
