Cover the Bed and Keep Full Access
The Truxedo 238101 TruXport is a soft roll up tonneau cover built for 6ft 6in beds on 1973 through 1996 Ford F-Series trucks. It clamps to the top of the bed rails, seals on all four sides and rolls forward to the cab so the whole bed stays usable when cargo is oversized.
Key Features
- Soft roll up cover sized for the 6ft 6in Ford F-Series bed
- Mounts on top of the bed rails with a clamp on design that needs no drilling or cutting
- Spring loaded SureTension control system holds the vinyl tight without manual adjustment
- RTxGrip multi tiered hook and loop seal keeps the edges held down along the rails
- Automatic slam latch system closes the cover at the tailgate and stays locked while the tailgate is locked
- Tear resistant gloss RTxVinyl with a marine grade exterior for weather, water, dirt and debris protection
- Ultraviolet resistant material to limit fading over long term outdoor use
- Low profile flush appearance with built in structural supports that resist sagging and water pooling
- Opens from either side of the tailgate with an easy grab pull handle
- TruGuide controls keep the cover straight as it rolls forward, with integrated straps to secure it behind the cab
- Weather seals on all four sides and dual latches at the tailgate
- Exact manufacturer part number: 238101
Fitment
| Vehicle Application | Bed Length | Restriction |
|---|---|---|
| 1973-1983 Ford F-100, F-150, F-250 and F-350 | 6ft 6in standard bed | Standard bed only |
| 1984-1986 Ford F-150, F-250 and F-350 | 6ft 6in standard bed | Standard bed only |
| 1987-1991 Ford F-150, F-250 and F-350 | 6ft 6in bed | Frame rails partially cover the stake pockets |
| 1992-1996 Ford F-150 | 6ft 6in bed | Excludes Stepside and Flareside beds |
| 1992-1996 Ford F-250 and F-350 | 6ft 6in bed | Standard bed only |
| 1997 Ford F-250 and F-350 Heavy Duty | 6ft 6in bed | Heavy Duty body style only |
Measure the bed from the inside of the bulkhead to the inside of the closed tailgate before ordering. The 238101 cover is built for the 6ft 6in bed and does not fit Stepside or Flareside beds, and it is not designed to work with a bed rail cap that covers the clamping surface.
Specifications
| Detail | Value |
|---|---|
| Brand | Truxedo |
| Manufacturer part number | 238101 |
| Product type | Soft roll up tonneau cover |
| Series | TruXport |
| Bed length | 6ft 6in |
| Cover material | Tear resistant gloss RTxVinyl |
| Exterior | Marine grade |
| Colour and finish | Black vinyl grain |
| Mounting | Clamp on above the bed rails |
| Rail clamps | Three per side |
| Profile height above bed rails | About 1.5 inches |
| Sealing | Weather seals on all four sides |
| Latching | Automatic slam latch with dual latches at the tailgate |
| Tension control | Spring loaded SureTension, preset and self adjusting |
| Opening | Either side of the tailgate |
| Installation | One person, no drilling or cutting |
| Installation time | Under 30 minutes |
| Barcode | 834418008958 |
| Warranty | 5 year |
What's Included
- One TruXport 238101 soft roll up tonneau cover assembly for the 6ft 6in Ford F-Series bed
- Vehicle specific clamp on mounting hardware
- Vehicle specific installation instructions
About Truxedo
Truxedo builds soft tonneau covers under the RealTruck group and focuses on vinyl roll up and folding designs that clamp to the factory bed rails. The TruXport line is the volume soft roll up cover in the range, built around a preset tension system, a hook and loop rail seal and a low profile appearance that keeps the bed sides visible.
Related Parts
FAQ
What is the 238101?It is the Truxedo TruXport soft roll up tonneau cover built for the 6ft 6in bed on 1973 through 1996 Ford F-Series trucks.
Does the tailgate still open with the cover fitted?Yes. The cover latches at the tailgate and cannot be opened from outside while the tailgate is locked, and the tailgate operates normally once the latches are released.
How much bed space is lost when the cover is rolled up?Very little. The cover rolls forward to the cab and secures with straps, leaving almost the entire bed open and keeping rear view visibility.
Is drilling required to install it?No. The cover clamps to the top of the bed rails with three clamps per side and needs no cutting, drilling or other modification.
Will it fit a Stepside or Flareside bed?No. Only standard 6ft 6in beds are covered, and the 1992 to 1996 F-150 Stepside is specifically excluded.
Does the cover need retensioning through the year?No. The spring loaded tension system is preset and adjusts itself, so there is no tension knob or strap to reset.
How well does it seal against weather?Weather seals run along all four sides and the hook and loop system holds the edges to the rails, which limits dust, rain and snow entry into the bed.
Can one person install it?Yes. The cover is designed for a single person to fit in under 30 minutes using the supplied hardware and instructions.
What warranty comes with the cover?The cover carries a 5 year warranty. Keep the purchase record because warranty support is handled through the manufacturer.
Installation Instructions
- Park the truck on a level surface, lower the tailgate and clean the top and inner surfaces of both bed rails.
- Unpack the 238101 cover and confirm the hardware and the vehicle specific instruction sheet are present before starting.
- Set the cover assembly on the bed with the roll positioned at the bulkhead and the tailgate end facing the tailgate.
- Attach the front rail to the bulkhead as shown in the instructions and check that it sits square to both bed sides.
- Lay the side rails along the bed rails and align them so the same overhang is present on each side.
- Fit three clamps per side under the bed rail lip and tighten them evenly so the rails stay parallel.
- Unroll the cover toward the tailgate and press the hook and loop seal onto the rails from the bulkhead back.
- Close the tailgate and engage the slam latch, then check that the latch releases and re-engages cleanly from both sides.
- Confirm the vinyl is even and free of wrinkles and that the tension system has pulled the surface flat.
- Roll the cover forward, secure it with the integrated straps and verify that the roll clears the rear window.
- Recheck all clamp fasteners after the first week of use and after any heavy load or wash cycle.
