SKU: 16965 | UPC: 690092176853
Vibrant -8AN Male Flare to Male -10 ORB Swivel 90 Degree Adapter - Anodized Black (Universal)
This 90-degree adapter from Vibrant Performance connects -8AN male flare fittings to -10 ORB male ports with a swivel design for precise alignment in oil systems. It suits universal applications in high-performance engines, transmissions, and dry sump setups across various vehicles. The durable construction ensures consistent oil flow and leak-free performance under demanding conditions.
Key Features
- Swivel ORB Connection: 360-degree rotation on the -10 ORB male side simplifies hose routing and eliminates stress on lines during installation
- Black Anodized Finish: Type II anodizing on 6061-T6 billet aluminum provides corrosion resistance and a sleek look that matches modern engine bays
- Precision CNC Machining: Tight tolerances guarantee leak-proof seals with -8AN flare and -10 ORB O-ring boss threads for dependable operation
- High-Flow Design: 90-degree bend fits tight spaces while maintaining unrestricted oil passage for optimal cooling and lubrication
- Universal Compatibility: Works with AN braided hoses and ORB ports on oil pumps, coolers, filters, and blocks in performance builds
Product Notes
- Pre-installed O-ring on ORB side. replace if damaged during handling
- Clean threads before assembly to prevent contamination in oil passages
- Small compact size ideal for custom fabrication projects
Installation Notes
- Professional installation recommended.
- Torque AN flare to 20-30 ft-lbs and ORB to 18-22 ft-lbs. no sealant needed on flare side
- Compatible with aluminum and steel oil system components
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| Universal | All | Performance Vehicles | Oil System Applications |
| 1997-2024 | Chevrolet | Corvette / Camaro | LS / LT Engines |
| 2004-2024 | Ford | Mustang / F-150 | Coyote / Modular Engines |
| 1986-2024 | GM | Various | LS-Series Swaps |
Why Choose Vibrant Performance?
- Earned trust of racing professionals worldwide for reliable oil system components
- Manufactured to strict quality standards for consistent performance
- Complete range of fittings provides one-stop solution for custom builds
Frequently Asked Questions
-
Q: Will this adapter work with standard AN oil hoses?
A: Yes, the -8AN male flare side threads directly onto -8AN female swivel hose ends for secure, dry-seal connections -
Q: What material and finish are used?
A: CNC-machined from 6061-T6 aircraft-grade aluminum with durable black Type II anodized coating for longevity -
Q: What is the warranty coverage?
A: Vibrant Performance offers a limited lifetime warranty against manufacturing defects when installed and used correctly
Shipping & Handling
- Method: UPS Ground or USPS Priority
- Availability: In stock - ships same or next business day
- Packaging: Securely boxed at 4 x 3 x 1.5 inches
- Weight: 0.2 lbs
