Wilwood UTV6-C/H left hand caliper black full view
Click to zoom in

Wilwood UTV6-C/H Left Hand Rotor - Black

Wilwood
WIL120-16567-BK
889545104035
Brake Kits - Performance Drill
11 Units In Stock - Ships Next Business Day
$ 306.83 $ 284.10
$ 284.10

SKU: 120-16567-BK   |   UPC: 889545104035

Wilwood UTV6-C/H Left Hand 6-Piston Forged Aluminum Caliper - Black

The Wilwood 120-16567-BK UTV6-C/H Left Hand (driver side) 6-Piston Forged Aluminum Caliper in Black is the ultimate high-performance brake upgrade for UTVs, sand cars, and custom off-road builds. This differential-bore 6-piston caliper is forged from high-strength aluminum for maximum strength at minimum weight, featuring Wilwood’s latest UTV-specific design for superior stopping power, heat management, and fade resistance. The sleek black powder coat finish adds aggressive styling while providing excellent corrosion protection in harsh off-road environments.

Key Features

  • 6-Piston Differential Bore Design: Even pad pressure and superior modulation for powerful, consistent braking
  • Forged Aluminum Construction: Lightweight, high-strength, and heat-resistant for reduced unsprung weight
  • Black Powder Coat Finish: Durable, corrosion-resistant, and race-ready appearance
  • UTV-Specific Mounting: Optimized for UTV6-C/H big brake kits and sand car applications
  • Stainless Steel Pistons: Corrosion resistant and excellent heat dissipation
  • Wilwood Engineering: Proven performance in the most demanding off-road and UTV racing environments

Specifications

Specification Detail
Part Number 120-16567-BK
Side Left Hand (Driver Side)
Pistons 6-Piston Differential Bore
Material Forged Aluminum Body with Stainless Pistons
Finish Black Powder Coat
Mounting UTV6-C/H Specific
Compatibility Wilwood UTV Big Brake Kits and custom UTV / sand car applications
Installation Bolt-On (requires matching rotor and pads)
Country of Origin United States
Warranty Limited Lifetime (Wilwood)
Shipping Weight Approx. 8 to 10 lbs

What's Included

  • One Wilwood UTV6-C/H Left Hand 6-Piston Caliper in Black
  • Installation Hardware (as applicable)
  • Instruction Sheet

Product Notes

  • Left-hand (driver side) caliper only order right-hand separately if needed
  • Designed for Wilwood UTV6 big brake kits and custom UTV/sand car builds
  • Requires matching Wilwood UTV rotors and high-performance brake pads
  • Professional installation and proper brake system bleeding required

Installation Notes

  • Estimated time: 1 to 2 hours per side, moderate difficulty
  • Bolt-on installation using Wilwood UTV-specific brackets and hardware
  • Always use new brake fluid and bleed the system thoroughly
  • Professional shop recommended for safety-critical brake work

This Part Fits

Application Notes
Universal UTV / Sand Car Wilwood UTV6-C/H Big Brake Kits and custom off-road builds requiring 6-piston calipers

Why Choose Wilwood UTV6-C/H Caliper?

  • Forged aluminum 6-piston design delivers massive stopping power with minimal weight
  • Black powder coat for aggressive styling and superior corrosion protection
  • Built in the USA and trusted by top UTV racers and builders

Frequently Asked Questions

  • Q: Is this the left or right caliper?
    A: This is the Left Hand (driver side) caliper only.
  • Q: What rotors and pads does it work with?
    A: Designed for Wilwood UTV-specific rotors and high-performance pads (sold separately).
  • Q: Does it fit my Polaris RZR?
    A: Yes, when used as part of a complete Wilwood UTV big brake kit for your specific model.
  • Q: What is the warranty?
    A: Covered by Wilwood Limited Lifetime Warranty.
