aFe Accord / TLX V6 5R Momentum Intake

Honda Accord and Acura TLX Momentum intake and scoop

aFe 56-70016R Takeda Momentum uses one pre-oiled cotton filter, XLPE tube and sealed sight-window housing. It includes model-specific bellows couplings and retains the original MAF, crankcase fitting and pinch clamp.

Key Features

• One 24-91103 five-layer pre-oiled cotton Pro 5R 7-1/2-inch inverted filter with 3-1/2-inch flange is selected. Both the tube and sealed sight-window housing are XLPE. The bill lists TWO alternative bellows couplings: 05-01523 (3.5 x 2.75-inch ID, 4 inches long) for Accord, and 05-01522 (3.5 x 3.25-inch ID, 4 inches long) for TLX; use the one for the actual car rather than installing both. It also lists ONE #048 clamp, ONE #052 clamp, TWO M4 screws with printed code 05-50491, ONE rubber pop mount and a T20 bit. Transfer TWO original sleeved housing grommets and TWO original mounting screws. Retain the original MAF, crankcase fitting and its ORIGINAL pinch clamp. No extension harness, new MAF, new vent hose or intake scoop is included. Filter-clamp use appears in the steps without a separate loose-hardware code. The battery-cable holder is released from the original airbox; keep the cable safely routed without inventing an undocumented new holder.
• Use the exact model-specific connections, original mounts and application requirements.

Fitment

Honda Accord 2013-2017 and Acura TLX 2015-2020 with the gasoline V6-3.5L engine. The exact current manufacturer pages and both linked manuals agree, correcting the older 2014 TLX headline. The existing TLX Base/SH-AWD 2015-2020 and Accord EX-L/Touring 2013-2017 rows are retained. Named-trim tables differ in detail, so actual V6 engine and inlet-housing confirmation remains necessary; the same trim name on a four-cylinder car is not approved. No later TLX turbo generation, four-cylinder or hybrid scope is inferred. The optional scoop fits TLX only and is sold separately.

Verify 56-70016R against the actual engine, sensor and vent connections, mounting locations and applicable emissions requirements before ordering.

Specifications

What's Included

One 24-91103 five-layer pre-oiled cotton Pro 5R 7-1/2-inch inverted filter with 3-1/2-inch flange is selected. Both the tube and sealed sight-window housing are XLPE. The bill lists TWO alternative bellows couplings: 05-01523 (3.5 x 2.75-inch ID, 4 inches long) for Accord, and 05-01522 (3.5 x 3.25-inch ID, 4 inches long) for TLX; use the one for the actual car rather than installing both. It also lists ONE #048 clamp, ONE #052 clamp, TWO M4 screws with printed code 05-50491, ONE rubber pop mount and a T20 bit. Transfer TWO original sleeved housing grommets and TWO original mounting screws. Retain the original MAF, crankcase fitting and its ORIGINAL pinch clamp. No extension harness, new MAF, new vent hose or intake scoop is included. Filter-clamp use appears in the steps without a separate loose-hardware code. The battery-cable holder is released from the original airbox; keep the cable safely routed without inventing an undocumented new holder.

About aFe Power

aFe Power develops application-specific intake, filtration, exhaust, cooling, tuning, suspension, drivetrain, and truck-performance components supported by product testing and documented installation requirements.

Related Parts

• Manufacturer product specifications for 56-70016R
• Exact illustrated installation manual
• Selected-media bench-flow comparison
• Manufacturer-linked dyno comparison and run configuration
• Shop the complete aFe Power collection

Frequently Asked Questions

Honda Accord 2013-2017 and Acura TLX 2015-2020 with the gasoline V6-3.5L engine. The exact current manufacturer pages and both linked manuals agree, correcting the older 2014 TLX headline. The existing TLX Base/SH-AWD 2015-2020 and Accord EX-L/Touring 2013-2017 rows are retained. Named-trim tables differ in detail, so actual V6 engine and inlet-housing confirmation remains necessary; the same trim name on a four-cylinder car is not approved. No later TLX turbo generation, four-cylinder or hybrid scope is inferred. The optional scoop fits TLX only and is sold separately.

One 24-91103 five-layer pre-oiled cotton Pro 5R 7-1/2-inch inverted filter with 3-1/2-inch flange is selected. Both the tube and sealed sight-window housing are XLPE. The bill lists TWO alternative bellows couplings: 05-01523 (3.5 x 2.75-inch ID, 4 inches long) for Accord, and 05-01522 (3.5 x 3.25-inch ID, 4 inches long) for TLX; use the one for the actual car rather than installing both. It also lists ONE #048 clamp, ONE #052 clamp, TWO M4 screws with printed code 05-50491, ONE rubber pop mount and a T20 bit. Transfer TWO original sleeved housing grommets and TWO original mounting screws. Retain the original MAF, crankcase fitting and its ORIGINAL pinch clamp. No extension harness, new MAF, new vent hose or intake scoop is included. Filter-clamp use appears in the steps without a separate loose-hardware code. The battery-cable holder is released from the original airbox; keep the cable safely routed without inventing an undocumented new holder.

No. Select the 3.5 x 2.75-inch 05-01523 for Accord or 3.5 x 3.25-inch 05-01522 for TLX, with the SMALL end on the throttle body.

Transfer the ORIGINAL crankcase fitting and ORIGINAL pinch clamp to the selected coupling port. No new vent hose or mini clamp is listed.

Transfer TWO original sleeved grommets, use TWO original housing screws and install the supplied rubber pop mount. Transfer the original MAF with supplied M4 screws and reconnect its original harness; no extension is listed.

Reinstall the original engine cover after intake installation. The separate Dynamic Air Scoop is optional for TLX only, requires the matching Momentum intake and factory-size battery, and is not an Accord accessory.

The actual selected-media linked chart measures 430 CFM versus stock 350 CFM at 7 inches H2O, about 22.9% higher. Its separate 400 CFM dry bar is not the filter supplied in this listing. The actual cotton-media 2016 TLX report at 4,791 rpm marks 192.15 minus 179.71 = 12.44 hp and 210.69 minus 197.03 = 13.66 lb-ft. Printed maxima are 221.47 versus 214.03 hp and 215.95 versus 204.01 lb-ft: +7.44 hp/+11.94 lb-ft peak-to-peak at different rpm. Both runs are September 16, 2019; SAE is 1.04 intake versus 1.03 baseline. Both runs list factory exhaust and OBD2 rpm. Gear, hood, tires, fan configuration and installation of the optional scoop are not specified. The headline marked-point gain is not the peak comparison, a guaranteed gain or an independent Accord test.

Recheck after 100-200 miles; no numeric torque is specified. The exact current manufacturer page and linked manual state that this product is not currently CARB exempt and is unavailable for purchase in California or use on a vehicle registered with the California DMV. Retailer claims that the scoop requires no EO do not override that current statement.

Installation Instructions

Verify aFe 56-70016R. Work on a cool engine. Pop off the engine cover. Disconnect the original MAF harness and its airbox clip; open the original crankcase pinch clamp and detach the crankcase fitting. Remove TWO original 10mm housing screws and loosen the throttle-body coupling clamp. Squeeze the battery-cable holder release tabs, detach it from the old airbox and remove the original intake. Transfer TWO original grommets with metal sleeves and install the supplied rubber pop mount in the new housing. Install the housing with BOTH original screws and lock the selected filter tabs into it, leaving its clamp loose. Select 05-01523 for Accord or 05-01522 for TLX and loosely fit it to the throttle body with its SMALL end toward the throttle body. Transfer the ORIGINAL pinch clamp to the coupling port, insert the ORIGINAL crankcase fitting and secure that clamp. Transfer the original MAF to the new tube using supplied M4 screws. Slide the tube into the FILTER FIRST, then the coupling, align and secure all clamps. Reconnect the original MAF, verify all connections and safe battery-cable routing, then REINSTALL the original engine cover. Recheck bolts, clamps and connectors after 100-200 miles. No numeric torque is specified.

Important Disclosures

Honda Accord 2013-2017 and Acura TLX 2015-2020 with the gasoline V6-3.5L engine. The exact current manufacturer pages and both linked manuals agree, correcting the older 2014 TLX headline. The existing TLX Base/SH-AWD 2015-2020 and Accord EX-L/Touring 2013-2017 rows are retained. Named-trim tables differ in detail, so actual V6 engine and inlet-housing confirmation remains necessary; the same trim name on a four-cylinder car is not approved. No later TLX turbo generation, four-cylinder or hybrid scope is inferred. The optional scoop fits TLX only and is sold separately. The exact current manufacturer page and linked manual state that this product is not currently CARB exempt and is unavailable for purchase in California or use on a vehicle registered with the California DMV. Retailer claims that the scoop requires no EO do not override that current statement. The actual cotton-media 2016 TLX report at 4,791 rpm marks 192.15 minus 179.71 = 12.44 hp and 210.69 minus 197.03 = 13.66 lb-ft. Printed maxima are 221.47 versus 214.03 hp and 215.95 versus 204.01 lb-ft: +7.44 hp/+11.94 lb-ft peak-to-peak at different rpm. Both runs are September 16, 2019; SAE is 1.04 intake versus 1.03 baseline. Both runs list factory exhaust and OBD2 rpm. Gear, hood, tires, fan configuration and installation of the optional scoop are not specified. The headline marked-point gain is not the peak comparison, a guaranteed gain or an independent Accord test.
