The Torque Solution TS-TB-FT25BK is a black silicone fiberglass thermal turbo blanket designed specifically for T25 and T28 internally gated turbos. It wraps the turbine housing and back housing to contain radiant heat, protect surrounding engine bay components, reduce under-hood ambient temperatures, and help the turbo spool faster by retaining exhaust heat where it belongs. Rated to 2,012 degrees Fahrenheit on the interior surface and 600 degrees on the exterior, the blanket ships with stainless steel wire and two stainless steel springs for a secure, rattle-free installation. This version is cut specifically for internally gated T25 and T28 turbos and includes the necessary clearance for the internal wastegate actuator arm.
What's Included
- 1x Black Silicone Fiberglass T25 / T28 Internally Gated Turbo Blanket
- 1x Stainless Steel Wire
- 2x Stainless Steel Springs
Why a Turbo Blanket Makes a Real Difference
Every T25 and T28 turbo radiates significant heat from the turbine housing and hot side back housing into the engine bay. That radiant heat raises under-hood ambient temperatures, soaks into the intake piping, heats the air charge before it reaches the intercooler, and transfers into surrounding components including fuel lines, brake lines, wiring, and intake couplers.
A turbo blanket acts as a radiant heat barrier between the turbine housing and everything around it. By containing that heat, the exhaust gases in the turbine housing retain more energy. More thermal energy in the exhaust stream means the turbine wheel spins up faster at lower RPM — reducing turbo lag and delivering power sooner on street driving where you are not always at full throttle. At the same time, the cooler exterior surface protects every component in the surrounding area and gives you more thermal headroom when packaging intake piping, intercooler piping, or electronics near the turbo.
Internally Gated Design
This blanket is cut and fitted specifically for T25 and T28 turbos with an internal wastegate. Internal wastegate turbos have an actuator arm that protrudes from the compressor housing side and connects to the internal flap inside the turbine housing. A universal or externally gated blanket will not accommodate that actuator arm and will either fit poorly or interfere with wastegate operation. The correct geometry is built in to clear the internal actuator arm while still providing full coverage of the turbine and back housing. If your T25 or T28 runs an external wastegate, see the TS-TB-FT3BK instead.
Compatible Turbos and Applications
This blanket fits any vehicle running a T25 or T28 internally gated turbocharger. The T25 and T28 are among the most widely used turbo frames across Japanese and European turbocharged passenger cars. Common platforms include turbocharged Subaru, Nissan, Mitsubishi, Honda, and European applications where a T25 or T28 frame turbo was fitted from the factory or installed as an aftermarket upgrade. Confirm your turbo frame designation and wastegate configuration before ordering.
| Application | Notes |
|---|---|
| T25 Internally Gated Turbo | All makes and models running a T25 frame internal wastegate turbo |
| T28 Internally Gated Turbo | All makes and models running a T28 frame internal wastegate turbo |
| Subaru Impreza WRX / STi (EJ20 / EJ25) | Verify turbo frame and internal gate configuration |
| Subaru Legacy GT | Verify turbo frame and internal gate configuration |
| Subaru Forester XT | Verify turbo frame and internal gate configuration |
| Nissan SR20DET / CA18DET applications | Verify turbo frame and internal gate configuration |
| Mitsubishi 4G63 applications | Verify turbo frame and internal gate configuration |
| Honda / Acura turbocharged applications | Verify turbo frame and internal gate configuration |
| Audi / VW turbocharged applications | Verify turbo frame and internal gate configuration |
Full Specifications
| Specification | Detail |
|---|---|
| Part Number | TS-TB-FT25BK |
| Color | Black |
| Outer Layer Material | Black Silicone Fiberglass |
| Interior Surface Max Temperature | 2,012 degrees F / 1,100 degrees C |
| Interior Continuous Use Limit | 1,832 degrees F / 1,000 degrees C |
| Exterior Direct Contact Limit | 600 degrees F / 316 degrees C |
| Exterior Radiant Heat Limit | 1,100 degrees F / 593 degrees C |
| Wastegate Configuration | Internal Wastegate Only |
| Turbo Fitment | T25 and T28 Frame Turbos |
| Hardware Included | 1x Stainless Steel Wire, 2x Stainless Steel Springs |
| California Prop 65 | Warning Applies |
Compare: Black vs. Other Torque Solution T25 Blanket Finishes
Torque Solution offers the T25 internally gated turbo blanket in three finish options. All three use the same internal construction and temperature ratings. The difference is cosmetic only.
| Part Number | Finish | MSRP Price |
|---|---|---|
| TS-TB-FT25BK | Black Silicone Fiberglass | $88.88 |
| TS-TB-LT25 | Volcanic Rock Finish | $111.10 |
| TS-TB-CT25 | Carbon Fiber Finish | $133.32 |
For externally gated T25 and T28 setups, the correct blanket is TS-TB-FT3BK.
About Torque Solution
Torque Solution designs and manufactures performance automotive components with a focus on forced induction, drivetrain, and engine management applications. Their thermal management lineup turbo blankets, exhaust wrap, and heat shielding is developed for high heat environments where factory solutions are inadequate. Torque Solution products are used in street builds, time attack, and drag racing across a wide range of turbocharged platforms.
Frequently Asked Questions
Does the Torque Solution TS-TB-FT25BK fit an internally gated T25 or T28 turbo?
Yes. The TS-TB-FT25BK is specifically designed for T25 and T28 turbos with an internal wastegate, with the correct cutout geometry to clear the internal wastegate actuator arm.
What is the difference between an internally gated and externally gated T25 or T28?
An internally gated turbo uses a wastegate flap built into the turbine housing, controlled by an actuator arm on the compressor side. An externally gated setup uses a separate wastegate mounted in the exhaust manifold or downpipe. This blanket is for internally gated turbos only. For externally gated applications, use the TS-TB-FT3BK.
How hot does the exterior surface get?
The exterior is rated for 600 degrees F under direct contact conditions and 1,100 degrees F for radiant heat. This is significantly cooler than an unshielded turbine housing and provides real protection for surrounding intake piping, wiring, and fuel lines.
Will this reduce turbo lag?
Yes. Retaining exhaust heat inside the turbine housing keeps more energy in the exhaust stream, helping the turbine wheel spool faster at lower RPM. The effect is most noticeable on street driving where you are not always entering a corner at full boost.
Does this lower intake air temperatures?
Yes. By reducing under-hood ambient temperatures, the blanket helps lower the temperature of air entering the intake piping and intercooler. The benefit is more significant on builds where the intake piping runs close to the turbo.
Does this work on my Subaru WRX or STi?
If your WRX or STi is running a T25 or T28 frame internally gated turbo, yes. Many factory Subaru EJ-series applications use T25 or T28 frame turbos with internal wastegates. Verify your specific turbo frame designation and wastegate type before ordering.
Is this street legal in California?
This is a thermal heat management accessory that does not modify emissions equipment and does not require a CARB EO number. California residents should note this product carries a Prop 65 warning.
California residents: This product contains chemicals known to the State of California to cause cancer and reproductive harm. See www.p65warnings.ca.gov.
