Turbosmart Water Cooled 6262 V-Band Inlet/Outlet A/R 0.82 External Wastegate TS-2 Turbocharger

Turbosmart
TURTS-2-6262B-VB082E
9329677028980
Turbochargers
4 Units In Stock - Ships Next Business Day
$ 2,480.99 $ 2,232.89
$ 2,232.89

SKU: TS-2-6262B-VB082E | UPC: 9329677028980

Turbosmart Water Cooled 6262 V-Band Inlet/Outlet A/R 0.82 External Wastegate TS-2 Turbocharger

The Turbosmart TS-2 6262 turbocharger brings water and oil cooling to high-performance universal applications on modified import and domestic engines. It fits custom builds on platforms like 2JZ, RB26, LS, and 4G63 with fabricated piping. Expect rapid transient response from its low rotating mass and aggressive aerodynamics for power from low to high RPM.

Key Features

  • Water &amp. Oil Cooled CHRA: 360-degree cooling protects bearings during extended high-boost runs and reduces heat soak.
  • Lightweight Turbine Housing: Investment cast construction weighs less than competitors for quicker spool and easier packaging.
  • Proprietary Bearing System: Dual ball bearing with unique shaft design cuts inertia for instant throttle response.
  • 62/83mm Compressor Wheel: Billet design with extended tips provides high flow at lower shaft speeds for broad powerband.
  • 62/56mm Turbine Wheel: High-efficiency blades in A/R 0.82 V-band housing maintain top-end power under heavy load.

Product Notes

  • External wastegate required and sold separately with provided port.
  • Use synthetic oil and distilled water mix for cooling lines to prevent failure.
  • Designed for modified engines only oversize shipping applies.

Installation Notes

  • Professional installation recommended.
  • Supply -4AN oil feed -10AN oil drain and -6AN water lines.
  • V-band clamps and gaskets needed for inlet outlet turbine connections.

This Part Fits

Year Make Model Submodel
1993-1998 Toyota Supra 2JZ-GTE
1989-2002 Nissan Skyline GT-R RB26DETT
1997-2004 Chevrolet Corvette LS1
1989-1998 Mitsubishi Eclipse GSX 4G63T
Universal Various Performance Builds -

Why Choose Turbosmart?

  • Motorsport pedigree from WTAC and World Time Attack wins.
  • Advanced materials like billet compressor and investment cast housings.
  • Factory-direct engineering and global support network.

Frequently Asked Questions

  • Q: What engines does the TS-2 6262 fit?
    A: Universal for 2JZ RB26 LS and similar 450-750hp builds with custom manifolds and piping.
  • Q: What materials are used in construction?
    A: Billet aluminum compressor 360-degree cooled steel CHRA high-temp investment cast turbine housing.
  • Q: What is the warranty coverage?
    A: 2-year unlimited mileage warranty when registered on Turbosmart site with proof of proper install.

Shipping & Handling

  • Method: UPS Ground or FedEx Ground
  • Availability: In stock - ships same or next business day
  • Packaging: Original Turbosmart box 19in x 17in x 17in
  • Weight: 21.3 lbs
