SKU: TS-0551-1011 | UPC: 9329677018516
Turbosmart WG38 Gen V Ultragate 38 14psi Blue
The Turbosmart WG38 Gen V Ultragate 38 14psi Blue is a precision external wastegate for turbocharged engines requiring accurate boost management. It fits universally on setups with 4.0 inch V-band inlet and outlet flanges found on most aftermarket manifolds and dump pipes. Expect faster spool quicker response and consistent boost across the RPM range for reliable power in street or track applications.
Key Features
- Gen V Design: Separate barrel and head construction simplifies field servicing without full disassembly
- 38mm Valve Size: Handles high exhaust flow rates up to 550hp ideal for mid to large turbochargers
- 14psi Base Spring: Factory preset at 14psi with easy spring swap options for custom boost levels from 5 to 26psi
- Forged Actuator Housing: 6061-T6 aluminum construction withstands extreme heat and pressure for long-term durability
- V-Band Clamps: Included stainless steel clamps and flanges ensure leak-free secure mounting
Product Notes
- Optional water cooling kit available for high-heat environments using 3/8 NPT ports
- Inspect valve seat annually for carbon buildup to maintain performance
- Arrives fully assembled with springs and hardware
Installation Notes
- Professional installation recommended.
- Mount vertically or horizontally with actuator facing up for optimal diaphragm function
- Requires matching 4.0 inch V-band flanges on manifold and dump tube
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| Universal | - | Turbocharged Vehicles | V-Band Exhaust 4 inch |
Why Choose Turbosmart?
- Hand-crafted in Sydney Australia since 1997 with performance community trust
- Strict quality control and in-house testing for proven reliability
- Innovative engineering from dedicated research facility
Frequently Asked Questions
-
Q: Will this wastegate fit my turbo setup?
A: Yes it bolts to any 4.0 inch V-band flanges on turbo outlet manifold and dump pipe common in aftermarket kits for Subaru Nissan Mitsubishi and more -
Q: What materials are used in construction?
A: 347 stainless steel housing Nitronic 60 valve and seat 17-7PH stainless spring forged 6061-T6 actuator for heat and corrosion resistance -
Q: What warranty coverage applies?
A: Backed by Turbosmart world-class support including warranty on manufacturing defects when installed and maintained correctly
Shipping & Handling
- Method: UPS Ground or FedEx
- Availability: In stock - ships same or next business day
- Packaging: Original Turbosmart box 10 x 8 x 7 inches
- Weight: 4.3 lbs
