Yukon Gear CK F8.8-SUPER Carrier Install Kit for 2015-2020 Ford Super 8.8in IRS Differential
The CK F8.8-SUPER from Yukon Gear is a full carrier and pinion installation kit engineered for the 2015 and newer Ford Super 8.8in independent rear suspension differential. This differential is used in the 2015-2020 Ford F-150 and 2015-2020 Ford Mustang. The CK F8.8-SUPER delivers a comprehensive set of components covering both carrier and pinion installation in one kit, including the super shim system that is unique to this application.
Features and Benefits
- Complete carrier and pinion installation kit engineered for the Ford Super 8.8in IRS differential
- Includes Timken carrier bearings and races for precise carrier positioning
- Timken pinion bearings and races for correct pinion depth and preload
- Pinion seal included to prevent rear differential fluid leaks after rebuild
- Complete super shim kit unique to the Super 8.8in application for exact backlash adjustment
- Crush sleeve for proper pinion preload during assembly
- Pinion nut included to complete the installation
- Manufactured to OEM and aftermarket tolerances for reliable long-term performance
- Covers all trim levels including base F-150, Lariat, Platinum, King Ranch, Raptor, and Mustang GT, EcoBoost, GT350
Fitment
| Year | Make | Model | Trim |
|---|---|---|---|
| 2015 | Ford | F-150 | All |
| 2016 | Ford | F-150 | All |
| 2017 | Ford | F-150 | All |
| 2018 | Ford | F-150 | All |
| 2019 | Ford | F-150 | All |
| 2020 | Ford | F-150 | All |
| 2015 | Ford | Mustang | All |
| 2016 | Ford | Mustang | All |
| 2017 | Ford | Mustang | All |
| 2018 | Ford | Mustang | All |
| 2019 | Ford | Mustang | All |
| 2020 | Ford | Mustang | All |
Specifications
| Attribute | Detail |
|---|---|
| Part Number | CK F8.8-SUPER |
| UPC | 883584109716 |
| Differential | Ford Super 8.8in IRS |
| Kit Type | Carrier and Pinion Install Kit |
| Included Components | Carrier bearings, carrier races, pinion bearings, pinion races, pinion seal, super shim kit, crush sleeve, pinion nut |
| Warranty | Yukon Gear limited warranty against defects in materials and workmanship |
What's Included
- Timken carrier bearings (2)
- Carrier bearing races (2)
- Timken pinion bearings (front and rear)
- Pinion bearing races (front and rear)
- Pinion seal
- Super shim kit for the Ford Super 8.8in IRS
- Crush sleeve
- Pinion nut
Frequently Asked Questions
- What differential does CK F8.8-SUPER fit? The CK F8.8-SUPER fits the Ford Super 8.8in independent rear suspension differential used in 2015-2020 Ford F-150 and 2015-2020 Ford Mustang.
- Does CK F8.8-SUPER include a pinion seal? Yes. The CK F8.8-SUPER includes a pinion seal as part of the complete installation kit.
- Is CK F8.8-SUPER compatible with the Ford Raptor? Yes. The F-150 Raptor from 2017 to 2020 uses the Super 8.8in IRS differential and is covered by the CK F8.8-SUPER.
- Does CK F8.8-SUPER fit the standard Ford 8.8in differential? No. The CK F8.8-SUPER is designed specifically for the Super 8.8in IRS used in fifth-generation (2015+) F-150 and S550 Mustang. It does not fit the traditional solid-axle 8.8in.
- Does CK F8.8-SUPER include a shim kit? Yes. The CK F8.8-SUPER includes the super shim kit designed specifically for the Super 8.8in application to allow precise backlash adjustment.
- What bearings are used in CK F8.8-SUPER? The CK F8.8-SUPER uses Timken carrier and pinion bearings for high load capacity and long service life.
- Is this kit covered under the Magnuson-Moss Warranty Act? Yes. As a consumer product sold in the United States, the CK F8.8-SUPER is subject to the provisions of the Magnuson-Moss Warranty Act. Yukon Gear provides a limited warranty against defects in materials and workmanship. Installation of aftermarket differential components does not void your vehicle manufacturer's warranty on unrelated systems under federal law.
- Can CK F8.8-SUPER be used for a gear ratio change? Yes. The CK F8.8-SUPER provides all the components needed to complete a ring and pinion gear ratio change or carrier swap in the Ford Super 8.8in IRS differential.
Installation Instructions
- Safely raise and support the vehicle. Drain differential fluid from the Super 8.8in IRS housing.
- Remove the rear axle shafts and disconnect the driveshaft from the differential pinion flange.
- Remove the differential carrier from the housing. Mark bearing caps for reassembly in original positions.
- Press off original carrier bearings using a bearing puller. Install new Timken carrier bearings from the CK F8.8-SUPER using a press.
- Remove the pinion nut and pinion flange. Drive out the old pinion from the housing.
- Remove old pinion bearing races with a brass punch. Install new races from the CK F8.8-SUPER fully seated in their bores.
- Press new pinion bearings onto the pinion as required for your differential setup.
- Install the new crush sleeve from the kit. Set pinion depth using the super shim kit as required to achieve the correct gear pattern.
- Install the new pinion seal from the CK F8.8-SUPER. Install pinion flange and new pinion nut. Torque to manufacturer specification while checking pinion rotating torque.
- Install the carrier with new carrier bearing shims from the kit. Verify backlash and gear contact pattern. Torque bearing caps to specification.
- Reinstall differential cover, fill with correct differential fluid to the proper level, and reinstall driveshaft and axle shafts. Lower vehicle.
