SKU: 234-5802 | UPC: 672036044664
ARP SB Chevy LT1 6.2L Main Stud Kit 2014-2023 Corvette Camaro SS CTS-V
ARP 234-5802 main stud kit secures the crankshaft in Gen V LT1 6.2L and LT4 engines powering 2014-2023 Chevrolet Corvette Camaro SS Chevrolet SS and Cadillac CTS-V. These studs replace factory bolts with stronger components to handle boosted and high-RPM applications. Built for performance engines this kit ensures block stability under extreme loads.
Key Features
- ARP2000 Alloy Material: Forged studs rated at 220000 PSI tensile strength resist fatigue and stretching in high-horsepower setups
- Complete Kit Contents: Eight 1/2in-20 x 7in main studs sixteen 3/8in-24 x 3.25in side bolts and hardened parallel washers for 4-bolt mains
- Precision Thread Rolling: Rolled threads provide consistent clamping force and superior load distribution over cut threads
- Black Oxide Finish: Resists corrosion and reduces friction during installation for accurate torque values
- Hex Design: 9/16in main nuts and 5/8in side bolts allow easy wrench access in tight engine bays
Product Notes
- Apply ARP Ultra-Torque assembly lube to threads and under washer faces for proper torque
- Torque mains to 75 ft-lbs side bolts to 25 ft-lbs following ARP instructions
- Kit weighs 2.1 lbs ships in 8in x 6in x 1.75in box
Installation Notes
- Professional installation recommended.
- Remove crankshaft and main caps to install studs clean all holes thoroughly
- Compatible with stock and aftermarket LT1/LT4 blocks uses factory main cap girdle
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2014-2019 | Chevrolet | Corvette | Stingray Z06 LT1 LT4 |
| 2016-2023 | Chevrolet | Camaro | SS LT1 ZL1 LT4 |
| 2014-2017 | Chevrolet | SS | Sedan LT1 |
| 2016-2019 | Cadillac | CTS-V | LT4 |
Why Choose ARP?
- Trusted by NHRA Top Fuel and Pro Stock teams for decades
- Manufactured in Southern California with exacting tolerances
- Proven to hold 2000+ HP engines without failure
Frequently Asked Questions
-
Q: Will this kit fit both LT1 and LT4 6.2L engines?
A: Yes ARP 234-5802 fits all Gen V LT1 and LT4 engines sharing the same 4-bolt main design in Corvette Camaro SS CTS-V and Chevrolet SS -
Q: What material are the studs made from?
A: ARP2000 chrome-moly alloy with 220000 PSI tensile strength far exceeding OEM bolts plus rolled threads for durability -
Q: What is the warranty on this kit?
A: Lifetime warranty against failure when installed and torqued per ARP specifications excludes abuse or improper lubrication
Shipping & Handling
- Method: UPS Ground
- Availability: In stock - ships same or next business day
- Packaging: Compact box 8 x 6 x 1.75 inches
- Weight: 2.1 lbs
