fifteen52 Alpen SV 17x8 6x130 BP 40mm ET 6.08 BS 84.1 Bore Frosted Graphite Wheel

Cast A356-T6 Sprinter Van Wheel in Frosted Graphite for 6x130 Applications

The fifteen52 Alpen SV NSVFG-78063+40 is purpose-built for the 6x130 bolt pattern found on the Mercedes-Benz Sprinter van and Volkswagen Crafter. Cast in A356-T6 aluminum alloy with a 17x8 footprint, a 40mm offset, and an 84.1mm center bore, this wheel bolts directly to Sprinter 2500 and 3500 models without adapters. The Frosted Graphite finish is a satin dark grey powder coat that holds up to the daily use demands of work van operators and Sprinter adventure builds alike. Load rating is 1,834 lbs per wheel, adequate for van loading within OEM payload limits. TPMS compatible. Each NSVFG-78063+40 is sold individually with a color-coded center cap.

This Part Fits

Key Features

• Cast A356-T6 aluminum alloy, one-piece construction designed for the 6x130 Sprinter bolt pattern
• 84.1mm center bore matches the Mercedes-Benz Sprinter hub directly, no adapter required
• Frosted Graphite satin dark grey finish resists road grime and is easily cleaned
• 1,834 lb load rating per wheel appropriate for cargo van and camper van payloads
• TPMS compatible with Sprinter OEM and aftermarket TPMS sensors
• 17x8 footprint accepts 245/70R17 or 265/65R17 all-terrain tires common in Sprinter builds
• MPN: NSVFG-78063+40

What is Included

• 1 x fifteen52 Alpen SV 17x8 6x130 40mm Frosted Graphite wheel (NSVFG-78063+40)
• 1 x color-coded fifteen52 center cap
• Lug hardware sold separately; Sprinter uses M14x1.5 lug bolts, not lug nuts

Installation Instructions

1. Confirm your Sprinter uses the 6x130 bolt pattern (2007 and newer NCV3 and VS30 generations) and an 84.1mm hub bore.
2. Use Mercedes-Benz M14x1.5 lug bolts; the NSVFG-78063+40 uses open lug seats compatible with standard Sprinter lug bolt geometry.
3. Torque lug bolts to 180 Nm (133 ft-lbs) in a star pattern, per Mercedes-Benz Sprinter specification.
4. Verify TPMS sensor fitment with your Sprinter generation before installation.
5. Re-torque after 50 miles of highway driving.
6. For high-mileage cargo routes, inspect wheels for impact damage every 6 months or as part of routine van maintenance.

Specifications

Frequently Asked Questions

Q: Does NSVFG-78063+40 fit all Mercedes-Benz Sprinter generations?
A: The 6x130 bolt pattern and 84.1mm center bore apply to the NCV3 (2007 to 2018) and VS30 (2019 to present) Sprinter generations. Verify your specific model year before ordering.

Q: Does NSVFG-78063+40 fit the Volkswagen Crafter?
A: The VW Crafter shares the 6x130 bolt pattern and 84.1mm center bore. Wheel fitment is generally compatible, but verify offset and clearance for your specific Crafter generation.

Q: What lug hardware do Sprinter vans use?
A: Mercedes-Benz Sprinters use M14x1.5 lug bolts, not lug nuts. Make sure to use the correct bolt-style hardware when mounting NSVFG-78063+40.

Q: Is the 40mm offset correct for a Sprinter van?
A: The OEM Sprinter offset range is 50 to 62mm. At 40mm, the NSVFG-78063+40 positions the wheel slightly further outboard than stock for a more aggressive stance. Verify clearance if running larger tires or suspension lifts.

Q: What tire size should I run with 17x8 on a Sprinter 2500?
A: 245/70R17 and 265/65R17 are the most common sizes for Sprinter adventure builds on a 17x8 wheel. Both provide adequate sidewall height for off-road use.

Q: Is NSVFG-78063+40 TPMS compatible?
A: Yes. The wheel is TPMS compatible. Verify that your Sprinter generation uses a compatible sensor frequency and that the sensor stem seats correctly in the 17x8 rim.

Q: Can I use hub-centric rings with NSVFG-78063+40?
A: The 84.1mm bore matches the Sprinter hub directly, so hub-centric rings are not required. If you are fitting these to a vehicle with a smaller hub diameter, rings are available to fill the gap.

Q: What is the load capacity of four NSVFG-78063+40 wheels combined?
A: Four wheels provide a combined load capacity of 7,336 lbs, which exceeds the GVWR of most Sprinter 2500 configurations. Verify the load rating per axle against your loaded van weight.
