Fifteen52 Apex 18x8.5 5x112/5x120 35mm ET 73.1mm Center Bore Frosted Graphite Wheel

Dual Bolt Pattern Street Wheel in Frosted Graphite for 5x112 and 5x120 Vehicles

The fifteen52 Apex STAFG-88551+35 is cast in A356-T6 aluminum alloy in a windowed 7-spoke design. The defining feature of this wheel is its dual bolt pattern: drilled for both 5x112 and 5x120, STAFG-88551+35 covers a wide span of European and domestic platforms without requiring separate part numbers. At 18x8.5 with a 35mm offset and 73.1mm center bore, this wheel fits VW Golf MK7 and MK8, Audi A3 and A4, BMW 3 Series and 5 Series, and Chevrolet Camaro among others. The Frosted Graphite finish is a satin dark grey powder coat over the cast alloy. Load rating is 1,600 lbs per wheel and the wheel weighs 24.13 lbs. TPMS compatible. Sold individually.

This Part Fits

Key Features

• Dual bolt pattern: drilled for both 5x112 and 5x120 for maximum platform compatibility
• Cast A356-T6 aluminum alloy in a windowed 7-spoke design
• Frosted Graphite satin grey finish on cast alloy
• 73.1mm center bore fits most VW/Audi, BMW, and Chevy Camaro hubs; use hub-centric rings for smaller hub diameters
• 1,600 lb load rating at 24.13 lbs per wheel
• TPMS compatible with European and domestic TPMS sensors
• MPN: STAFG-88551+35

What is Included

• 1 x fifteen52 Apex 18x8.5 5x112/5x120 35mm Frosted Graphite wheel (STAFG-88551+35)
• 1 x fifteen52 center cap
• Lug hardware sold separately; confirm thread pitch for your vehicle

Installation Instructions

1. Confirm your vehicle uses either a 5x112 or 5x120 bolt pattern before purchase.
2. Measure your hub diameter; install hub-centric rings to 73.1mm if your hub is smaller.
3. Use lug hardware appropriate for your vehicle: M14x1.5 open-ended bolts for VW/Audi, 12x1.5 lug nuts for BMW and Camaro.
4. Torque hardware to manufacturer spec in a star pattern: 88 to 103 ft-lbs for VW/Audi, 89 ft-lbs for BMW, 100 ft-lbs for Camaro.
5. Verify TPMS sensor seating before final torque.
6. Re-torque after 25 to 50 miles of driving.

Specifications

Frequently Asked Questions

Q: What is a dual bolt pattern wheel?
A: A dual bolt pattern wheel is drilled with two overlapping lug hole patterns so the same wheel can mount on vehicles using either bolt pattern. STAFG-88551+35 is drilled for both 5x112 and 5x120, which means it fits VW/Audi platforms and BMW/Chevy platforms from a single part number.

Q: Does the dual drilling weaken the wheel?
A: No. The lug hole locations are engineered so that the structural load paths remain intact. The 1,600 lb load rating confirms this wheel meets strength certification regardless of which bolt pattern is used.

Q: What hub-centric rings do I need for a VW Golf GTI?
A: VW Golf GTI MK7/MK8 hubs are 57.1mm. You will need hub-centric rings that step down from 73.1mm to 57.1mm.

Q: What hub-centric rings do I need for a BMW F30 3 Series?
A: BMW F30 hubs are 72.6mm. Rings stepping from 73.1mm to 72.6mm are a very minimal gap and are still recommended to prevent any vibration.

Q: Does STAFG-88551+35 fit the Toyota GR Supra?
A: Yes. The 2021 and newer GR Supra uses a 5x112 bolt pattern. Hub-centric rings from 73.1mm to 56.1mm are needed.

Q: What lug nuts are needed for the Camaro with 5x120?
A: The Chevrolet Camaro uses 12x1.5 lug nuts. Use acorn-style lug nuts with an appropriate seat angle.

Q: Is STAFG-88551+35 available in other finishes?
A: The Apex model is available in Rally White, Gloss White, Speed Silver, and other finishes. STAFG-88551+35 designates the Frosted Graphite color specifically.

Q: What tire size pairs best with 18x8.5 35mm on a Golf GTI?
A: 225/40R18 and 235/40R18 are common performance street sizes for the Golf GTI on an 18x8.5 wheel. Both provide adequate clearance at stock ride height.
