Aeromotive Fuel Pumps, Regulators & Fuel Systems

Shop Aeromotive fuel pumps, pressure regulators, filters, tanks, fuel rails, fittings, wiring, controllers, and service parts for street, track, racing, and custom fuel systems. Select by exact Aeromotive part number, fuel type, operating pressure, required flow, electrical demand, plumbing size, and vehicle fitment. For application-specific parts, verify the complete year, make, model, engine, and configuration before ordering.

Choose Your Part

Build the system around the engine’s actual requirements rather than a free-flow pump rating. Confirm target power, gasoline or alternative-fuel compatibility, base pressure, boost pressure, required flow at operating pressure, system voltage, duty cycle, and intended use. Then match the pump, regulator, filters, lines, fittings, wiring, tank venting, and return strategy as one coordinated system.

Fuel Pumps and Pump Controllers

Aeromotive offers in-tank, external, mechanical, brushless, and spur-gear fuel-pump configurations. Compare published flow at the pressure your engine will use, not only the maximum horsepower label. High-current pumps require properly sized power and ground wiring, circuit protection, relays or a compatible controller, and careful voltage-drop control.

Pressure Regulators, Filters, and Plumbing

Match each regulator to EFI or carbureted pressure, bypass or returnless operation, boost reference, port threads, and fuel compatibility. Follow the exact pump’s filtration requirements and verify filter micron rating, element area, mounting direction, and service interval. AN flare, ORB, and NPT connections use different threads and sealing methods and are not interchangeable.

Fuel Tanks, Cells, Rails, and Complete Systems

Vehicle-specific tanks and pump modules must match the full vehicle configuration, including body style, engine, chassis, filler, vent, sender, and mounting details. Fuel rails require the correct injector style and spacing, brackets, ports, fittings, and engine-bay clearance. Universal tanks and cells should be selected by dimensions, mounting, capacity, plumbing, and complete system design.

Fuel Compatibility and Safe Installation

Compatibility with gasoline does not automatically establish compatibility with E85, methanol, diesel, or other fuels. Verify every wetted component, including pumps, seals, filters, foam, hoses, regulators, and fittings. Fuel-system work should be completed away from ignition sources, using approved components, and the finished system should be pressure-tested and checked for leaks before operation.

Shop Related Fuel-System Parts

• Fuel Pumps
• Fuel-System Fittings
• DeatschWerks Fuel Components
• Radium Engineering Fuel Components

Frequently Asked Questions

How do I choose an Aeromotive fuel pump for my power goal?

Use Aeromotive’s current flow data at your required operating pressure, then account for fuel type, boost, voltage at the pump, and duty cycle. Include a reasonable capacity reserve and size the wiring, filters, lines, regulator, and tank venting to support the pump.

Can Aeromotive components be used with E85 or methanol?

Only when Aeromotive identifies the exact part as compatible. Confirm every wetted component in the system because compatibility cannot be inferred from another product in the same family.

Do I need a return-style fuel system?

That depends on the pump, regulator, controller, vehicle strategy, and required flow. Adjustable bypass regulators normally need an appropriately sized return line, while returnless and PWM-controlled systems require their documented layouts.

Where should Aeromotive fuel filters be installed?

Follow the instructions for the exact pump and fuel. A coarse pre-filter protects the pump without excessive inlet restriction, while a finer post-filter protects downstream injectors or carburetor components.

Can I mix AN, ORB, and NPT fittings?

No. These connection types use different threads and sealing methods. Match the fitting standard, size, sealing surface, and hose specification shown for each component.

How should I size fuel-pump wiring?

Use the pump’s published current draw, circuit length, controller or relay requirements, and allowable voltage drop. Follow Aeromotive’s instructions and use suitable circuit protection, connections, grounds, and wire gauge.

Are Aeromotive fuel tanks direct replacements?

Only when the exact listing identifies the vehicle application. Confirm year, make, model, body style, engine, chassis, filler, vent, sender, mounting, and included hardware before ordering.

What should I verify before ordering an Aeromotive part?

Confirm the exact part number, vehicle or universal application, fuel type, pressure and flow requirements, port threads, dimensions, mounting orientation, electrical demand, included components, and any use restriction shown on the product page.
