SKU: 230-7303 | UPC: 672036008437
ARP Chevy LS Torque Converter Bolt Kit - Fits 1997+ GM LS Engines
Secure your torque converter to the flexplate with this ARP 230-7303 bolt kit designed for 1997 and later Chevy LS engines in cars and trucks. The six 7/16-20 x 1.380 inch bolts made from ARP2000 alloy maintain clamp load under high stress for dependable power transfer. Perfect for performance upgrades in Camaro Corvette Silverado and more.
Key Features
- ARP2000 Alloy Construction: High-strength material resists fatigue and handles extreme torque in racing environments
- Precision-Rolled Threads: 7/16-20 threads ensure maximum engagement and accurate torque values every time
- Exact OEM-Length Bolts: 1.380 inch length matches factory specs for drop-in fit without modifications
- Black Oxide Finish: Provides corrosion resistance and reduces galling during installation
- Complete 6-Bolt Set: Includes all necessary hardware for GM LS flexplate-to-converter mounting
Product Notes
- Inspect flexplate for wear before installing new bolts
- Apply ARP Ultra-Torque to threads and under bolt heads
- Packaged in protective kit box for safe transit
Installation Notes
- Professional installation recommended.
- Torque to 65 ft-lbs using ARP lube in criss-cross sequence
- Compatible with stock and aftermarket LS flexplates
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| 1997-2004 | Chevrolet | Corvette | LS1 |
| 1998-2002 | Chevrolet | Camaro | LS1 Z28/SS |
| 1999-2007 | Chevrolet | Silverado 1500 | 4.8L/5.3L/6.0L |
| 2004-2006 | Chevrolet | GTO | LS1/LS2 |
| 2005-2013 | Chevrolet | Corvette | LS2/LS7 |
| 1999-2007 | GMC | Sierra 1500 | 4.8L/5.3L/6.0L |
| 1998-2002 | Pontiac | Firebird | LS1 |
Why Choose ARP?
- ARP fasteners power wins in NHRA IHRA and NASCAR racing
- Every bolt undergoes rigorous testing for load capacity
- Engineered in the USA with exacting tolerances for LS applications
Frequently Asked Questions
-
Q: Will this kit fit all GM LS engines?
A: Yes it fits Gen III/IV LS engines including LS1 LS2 LS6 LS7 LQ4 LQ9 and truck variants from 1997 to present in Chevy GMC and Pontiac vehicles -
Q: What material and finish do the bolts have?
A: Forged ARP2000 chrome moly alloy with black oxide coating for strength and rust protection -
Q: What is the recommended torque and warranty?
A: Torque to 65 ft-lbs with ARP Ultra-Torque backed by ARP limited lifetime warranty against manufacturing defects
Shipping & Handling
- Method: UPS Ground
- Availability: In stock - ships same or next business day
- Packaging: Compact kit box 7in x 5.5in x 1in
- Weight: 0.25 lbs
