Trail-Ready Spot Lighting Engineered for the Ford Bronco Platform
The Baja Designs 440087UP Squadron Pro 2.0 A-Pillar Kit brings 5,921 lumens of forward-throwing spot light to the 2021-2025 Ford Bronco and 2022-2025 Ford Bronco Raptor without cutting, drilling, or rewiring your factory harness. The upfitter (UP) harness routes cleanly through the Bronco's A-pillar channel and terminates with a 4-pin Deutsch connector at each light pod, providing corrosion-resistant and rattle-proof electrical contact designed for the worst trails you can find. The Squadron Pro 2.0 platform is the same lighting used by Baja 1000 class vehicles, scaled for street-legal enthusiast builds. Whether you are running Moab, Baja, or your local trail system at night, the 440087UP gives you the reach and reliability to do it confidently.
Key Features
- Baja Designs 440087UP Squadron Pro 2.0 A-Pillar Kit, purpose-built for 2021-2025 Ford Bronco and 2022-2025 Bronco Raptor
- 5,921 lumens per light pod at 65 watts with spot beam pattern for maximum long-range projection
- Upfitter (UP) harness for clean A-pillar routing without factory wiring modification
- 4-pin Deutsch connectors for waterproof, vibration-resistant electrical connections
- IP69K waterproof rating for river crossings and pressure washing
- RGBW backlight system with 9 selectable colors
- Clear polycarbonate lens for high-transmission, long-life light output
- Mounts to Bronco factory A-pillar locations without drilling
- Baja Designs limited lifetime warranty
Fitment
| Year Range | Make | Model |
|---|---|---|
| 2021-2025 | Ford | Bronco |
| 2022-2025 | Ford | Bronco Raptor |
Specifications
| Detail | Value |
|---|---|
| MPN | 440087UP |
| Brand | Baja Designs |
| Light Type | Squadron Pro 2.0 |
| Beam Pattern | Spot |
| Lens Color | Clear |
| Lumens (per light) | 5,921 |
| Watts (per light) | 65W |
| Backlight | RGBW, 9 colors |
| IP Rating | IP69K |
| Connector Type | 4-pin Deutsch |
| Harness Type | Upfitter (UP) |
| Warranty | Limited Lifetime |
What's Included
- 2x Baja Designs Squadron Pro 2.0 LED light pods (spot, clear)
- Ford Bronco A-pillar mounting brackets
- Upfitter wiring harness with 4-pin Deutsch connectors
- All mounting hardware and fasteners
- Installation instructions
About Baja Designs
Baja Designs is a San Marcos, California based off-road LED lighting company founded by and for off-road racers. Each product is engineered and optically validated in-house, and Baja Designs lights have proven themselves in the Baja 1000 and other brutal desert racing events. The Squadron Pro 2.0 is the current-generation version of one of their most versatile and popular lighting platforms.
Related Parts on Our Site
Frequently Asked Questions
What is the Baja Designs 440087UP?The Baja Designs 440087UP is the Squadron Pro 2.0 A-Pillar Light Kit with an upfitter harness designed specifically for the 2021-2025 Ford Bronco and 2022-2025 Ford Bronco Raptor. It outputs 5,921 lumens per light in a spot beam pattern with IP69K waterproofing, RGBW color backlighting, and 4-pin Deutsch connectors.
Does the 440087UP fit the Bronco Raptor?Yes. The Baja Designs 440087UP is confirmed to fit both the standard 2021-2025 Ford Bronco and the 2022-2025 Ford Bronco Raptor. The mounting brackets are designed around the A-pillar profile shared across Bronco variants.
What does UP mean in the 440087UP part number?UP designates the upfitter harness configuration. This harness is designed to route through the factory A-pillar channel and integrate with the Bronco's existing electrical architecture, avoiding surface-mount runs or relay box installations.
Is the Baja Designs 440087UP waterproof?Yes. The Squadron Pro 2.0 carries an IP69K rating, which is the top waterproof standard, meaning it is sealed against high-pressure water jets and sustained submersion. It is fully rated for river crossings and regular pressure washing.
What beam pattern does the 440087UP use?The 440087UP uses a spot beam pattern, which focuses light output into a tight, forward-projecting cone for maximum distance throw. This is the preferred configuration for high-speed off-road driving and dark trail environments where far reach matters most.
Will these lights work with the Bronco's factory switch controls?The 440087UP uses the upfitter harness, which integrates with the Bronco's factory upfitter switches when properly connected. Refer to the included wiring diagram and your Bronco's owner manual for the correct upfitter switch wiring positions.
How many lumens do the Squadron Pro 2.0 lights produce?Each Squadron Pro 2.0 light pod in the 440087UP kit produces 5,921 lumens at 65 watts. As a pair, the kit delivers nearly 12,000 lumens of forward-directed spot illumination when both pods are at full output.
Does Baja Designs warrant the 440087UP?Yes. Baja Designs backs the 440087UP with a limited lifetime warranty against defects in materials and workmanship for the original purchaser.
Installation Instructions
- Disconnect the Ford Bronco battery negative terminal before beginning any electrical work
- Mount the included A-pillar brackets to the factory mounting points on the Bronco, using the included hardware
- Attach the Squadron Pro 2.0 pods to the brackets and loosely tighten to allow aim adjustment
- Route the upfitter harness through the A-pillar channel to the dash, following the factory cable path
- Connect the 4-pin Deutsch connectors to each light pod
- Connect harness leads to the appropriate upfitter switch terminals or to a fused switched 12V source
- Reconnect battery and confirm both pods illuminate and RGBW backlights function
- Aim each light pod at the desired target distance and fully torque all mounting hardware
