Click to zoom in
SKU: 09.C397.13 / UPC: 8020584218501
Brembo 15-16 BMW 228i xDrive/17-18 230i Front Premium OE Equivalent Rotor
Brembo UV Coated rotors provide direct OE replacement for select BMW 2 Series, 3 Series and 4 Series models from 2012 to 2021, including 228i xDrive, 230i, M240i and more. High carbon cast iron construction minimizes noise and vibration for consistent braking and driving comfort. Fixing screw kit ensures simple installation.
Key Features
- UV Coating – Solvent-free finish protects disc surfaces including braking plates from corrosion
- High Carbon Cast Iron – Minimizes noise and vibration while delivering reliable performance
- Fixing Screw Kit – Includes all hardware needed for straightforward installation
- Intelligent Markings – Displays part number and minimum thickness for easy reference
- OE Specifications – Matches or exceeds factory standards as direct replacement
- Pad Compatibility – Pairs with Brembo NAO/Ceramic or Low Met formulations
Specifications
| Detail | Value |
|---|---|
| Brand | Brembo |
| Type | Front Premium UV Coated Rotor |
| Compatibility | 2012-2021 BMW 2/3/4 Series select models |
| MPN | 09.C397.13 |
| Position | Front (Left/Right) |
| Rotor Diameter | 348 mm |
| Rotor Thickness | 30 mm |
| Minimum Thickness | 28.4 mm |
| Height | 68 mm |
| Vane Style | 48 Curved Vents |
| Material | High Carbon Cast Iron |
| Pilot Diameter | 72.6 mm |
| Lug Count | 5 |
| Shipping Weight | 28.8 lbs |
| Box Dimensions | 13.4 x 13.4 x 2.4 inches |
| Country of Origin | Italy |
| Warranty | 24 Month / 24,000 Mile Limited |
Whats Included
- 1 x UV Coated Front Brake Rotor
- Fixing screw kit with hardware
Product Notes
- Replace rotors and pads together to restore braking performance
- Intelligent markings indicate part number and minimum thickness
- Inspect abutment clips and pad wear sensors during installation
This Part Fits
| Year Range | Make | Model | Notes |
|---|---|---|---|
| 2014-2016 | BMW | 228i | Base |
| 2015-2016 | BMW | 228i xDrive | Base |
| 2017-2021 | BMW | 230i | Base |
| 2017-2021 | BMW | 230i xDrive | Base |
| 2016-2018 | BMW | 320i | Base |
| 2016-2018 | BMW | 320i xDrive | Base |
| 2014-2015 | BMW | 328d xDrive | Base |
| 2012-2016 | BMW | 328i | Base |
| 2014-2016 | BMW | 328i GT xDrive | Base |
| 2013-2016 | BMW | 328i xDrive | Base |
| 2016 | BMW | 330e | Base |
| 2018 | BMW | 330e | Base |
| 2017 | BMW | 330e iPerformance | |
| 2017-2018 | BMW | 330i | Base |
| 2017-2019 | BMW | 330i GT xDrive | Base |
| 2017-2019 | BMW | 330i xDrive | Base |
| 2012-2015 | BMW | 335i | Base |
| 2014-2016 | BMW | 335i GT xDrive | Base |
| 2013-2015 | BMW | 335i xDrive | Base |
| 2016-2018 | BMW | 340i | Base |
| 2017-2019 | BMW | 340i GT xDrive | Base |
| 2016-2018 | BMW | 340i xDrive | Base |
| 2014-2016 | BMW | 428i | Base |
| 2015-2016 | BMW | 428i Gran Coupe | Base |
| 2014-2016 | BMW | 428i xDrive | Base |
| 2014-2016 | BMW | 435i xDrive | Base |
| 2015-2016 | BMW | 435i xDrive Gran Coupe | Base |
| 2017-2020 | BMW | 440i | Base |
| 2017-2020 | BMW | 440i Gran Coupe | Base |
| 2017-2020 | BMW | 440i xDrive | Base |
| 2017-2020 | BMW | 440i xDrive Gran Coupe | Base |
| 2013-2015 | BMW | ActiveHybrid 3 | Base |
| 2014-2016 | BMW | M235i | Base |
| 2015-2016 | BMW | M235i xDrive | Base |
| 2017-2021 | BMW | M240i | Base |
| 2017-2021 | BMW | M240i xDrive | Base |
| 2015-2016 | BMW | 428i xDrive Gran Coupe | Base |
| 2017-2020 | BMW | 430i | Base |
| 2017-2020 | BMW | 430i Gran Coupe | Base |
| 2017-2020 | BMW | 430i xDrive | Base |
| 2017-2020 | BMW | 430i xDrive Gran Coupe | Base |
| 2014-2016 | BMW | 435i | Base |
| 2015-2016 | BMW | 435i Gran Coupe | Base |
Why Choose Brembo?
- Meets or exceeds OEM specifications for dependable braking
- UV coating offers corrosion protection without solvents
- High carbon iron reduces noise and vibration effectively
- Hardware kit simplifies installation process
Frequently Asked Questions
- Q: Is this a direct OE replacement rotor?
- A: Yes, designed to meet or exceed OEM specs for plug-and-play fitment
- Q: Does it include installation hardware?
- A: Yes, complete fixing screw kit is provided
- Q: What brake pads work best with this rotor?
- A: Brembo NAO/Ceramic or Low Met pads for optimal performance
Shipping & Handling
- Method: UPS Ground / FedEx Ground
- Availability: In stock – ships same or next business day
- Packaging: Secure Brembo box with protective inserts
