Brembo 05-12 Porsche 911 Carrera/S/05-12 Boxster S/06-12 Cayman S Front Right Brake Wear Sensor

Never Miss a Brake Pad Change on Your Porsche 911, Boxster S, or Cayman S

The Brembo A00417 is a direct OE-specification front right brake pad wear sensor for the 2005-2012 Porsche 911 Carrera and Carrera S (997 platform), 2005-2012 Porsche Boxster S (987), and 2006-2012 Porsche Cayman S (987C). Brembo A00417 monitors front right brake pad thickness electronically and triggers your dashboard warning light the moment pad material reaches minimum safe depth, giving you time to schedule service before rotor damage occurs. Brembo strongly recommends replacing A00417 with every front brake pad service to ensure your warning system functions correctly throughout the life of each new pad set.

Key Features

• Brembo A00417 OE-equivalent front right brake pad wear sensor for Porsche 997, 987, and 987C platforms
• Electronic sensor triggers brake warning light when pad material reaches minimum thickness
• Made to OE specifications for direct, plug-in replacement with no wiring modification
• Brembo recommends replacing A00417 with every brake pad replacement to maintain proper warning system function
• Fits 2005-2012 Porsche 911 Carrera and Carrera S, 2005-2012 Boxster S, 2006-2012 Cayman S
• Position specific: Front Right only
• Sold individually

Fitment

Specifications

What's Included

• 1x Brembo A00417 front right brake pad wear sensor with connector

Frequently Asked Questions

A00417 fits the 2005-2012 Porsche 911 Carrera and Carrera S (997 platform), 2005-2012 Porsche Boxster S (987), and 2006-2012 Porsche Cayman S (987C). It is a front right position sensor — it does not cover the front left or rear axle.

Brembo A00417 is the front right brake pad wear sensor. If you need the front left sensor for your Porsche 997, 987, or 987C, verify the correct Brembo part number for that position before ordering.

Replace A00417 every time you install new front brake pads. The sensor is a single-use component — once it contacts the rotor and activates the warning light, the sensor itself is damaged and cannot be reused. Installing a new A00417 with each pad change ensures the warning system functions correctly through the life of the new pads.

A00417 is compatible with most aftermarket front brake pads designed for the Porsche 997, 987, and 987C platforms, as long as the pads include a sensor slot or wire channel at the correct depth. Confirm aftermarket pad compatibility with your brake pad supplier before installation.

A00417 crosses to Porsche OE numbers 99761275901, 99761275900, 99761275601, and 99761275600. These Porsche part numbers have been superseded over production years — A00417 covers the current supersession.

Technically yes, but it is not recommended. A missing or broken wear sensor disables your brake pad wear warning system, leaving you without any electronic alert before pads wear into the rotor. Rotor damage from worn-through pads is significantly more expensive to repair than replacing A00417 at every pad change.

A00417 is sold as a single sensor. For a complete front axle service, you will need one A00417 for the front right and the appropriate Brembo part number for the front left if that sensor also requires replacement.

A00417 is confirmed for the 911 Carrera and Carrera S (997) only. The 997 Turbo, GT3, GT3 RS, and GT2 use different brake calipers and may require different wear sensor part numbers. Verify fitment via Porsche or Brembo application guides before ordering for those variants.

Installation Instructions

1. Safely raise the vehicle and support on jack stands. Remove the front right wheel.
2. Locate the brake pad wear sensor wire running from the brake caliper to the chassis connector. Disconnect the sensor connector from the chassis wiring harness.
3. Remove the caliper mounting bolts and slide the caliper off the rotor. Support the caliper with a wire hook.
4. Remove the old brake pads from the caliper bracket. Note the position of the old wear sensor in the pad slot or retaining clip.
5. Pull the old sensor wire free from any retaining clips along the caliper or bracket.
6. Insert the new Brembo A00417 sensor into the designated slot on the inboard brake pad (typically a small cutout near the top of the pad backing plate).
7. Route the A00417 sensor wire back through the original retaining clips and along the caliper bracket to avoid contact with moving parts.
8. Plug the A00417 connector into the chassis wiring harness until it clicks securely.
9. Install fresh brake pads, reassemble the caliper, and reinstall the wheel.
10. Start the vehicle and verify the brake warning light extinguishes after a few seconds. If the light remains on, check the connector seating and sensor installation position.
