Energy Suspension 09-18 Ram 1500 Ext Cab/ Crew Cab Body Mount Set - Red

Replace Cracked and Collapsed Factory Rubber with Polyurethane Body Mounts That Hold Cab Alignment on a Lifted Ram 1500

The Energy Suspension 5.4117R is the Hyper-Flex polyurethane body mount set for the 2009-2018 Ram 1500 Extended Cab and Crew Cab in red. Factory rubber body mounts on the DS-generation Ram 1500 compress, crack, and distort over time, allowing the cab to shift on the frame and causing alignment issues, cab-to-bed gaps, squeaks, and accelerated wear on surrounding hardware. The ENG5.4117R replaces each OEM rubber mount with Energy Suspension's proprietary Hyper-Flex polyurethane compound, which combines a compliant enough durometer to maintain street ride quality with the durability and dimensional stability to outlast rubber by a significant margin. Each bushing in the 5.4117R set uses a zinc-plated steel insert ring molded in place for reinforcement and long-term crush resistance. Designed for 2009-2018 Ram 1500 Crew Cab and Extended Cab body configurations.

Key Features

• Energy Suspension ENG5.4117R Hyper-Flex polyurethane body mount set for 2009-2018 Ram 1500 Crew Cab and Extended Cab
• Replaces distorted and cracked factory rubber body mounts that cause cab misalignment and frame movement
• Hyper-Flex polyurethane maintains street ride quality while delivering far greater durability than OEM rubber
• Zinc-plated steel insert ring molded into each bushing for added crush resistance and long-term dimensional stability
• Red color with Energy Suspension branding
• Compatible with 2009-2018 Ram 1500 Crew Cab and Extended Cab configurations
• Made in USA by Energy Suspension

Fitment

Specifications

What's Included

• Complete body mount bushing set for 2009-2018 Ram 1500 Extended Cab and Crew Cab (quantity varies per application)
• Zinc-plated steel insert rings molded into each bushing

About Energy Suspension

Energy Suspension has manufactured Hyper-Flex polyurethane suspension components in the United States since 1983. Based in San Clemente, California, Energy Suspension produces application-specific bushing sets, body mounts, sway bar bushings, and supporting hardware for thousands of domestic and import vehicle applications. The Hyper-Flex compound is formulated to deliver significantly longer service life than OEM rubber while maintaining ride quality appropriate for street-driven vehicles.

Frequently Asked Questions

The Energy Suspension 5.4117R is the Hyper-Flex polyurethane body mount set for the 2009-2018 Ram 1500 Extended Cab and Crew Cab in red. It replaces all factory rubber body mounts with Energy Suspension's Hyper-Flex polyurethane compound, which uses zinc-plated steel insert rings for crush resistance and delivers significantly longer service life than OEM rubber while maintaining a street-appropriate ride quality.

The Energy Suspension 5.4117R fits the 2009-2018 Ram 1500 in Extended Cab (Quad Cab) and Crew Cab body configurations. It does not cover the Regular Cab Ram 1500. Confirm your cab configuration before ordering. The application note on Energy Suspension's documentation lists this as an 09-18 Ram 1500 Extended Cab and Crew Cab set.

Common symptoms of worn or collapsed body mounts on the Ram 1500 include cab-to-bed misalignment, squeaking or clunking from the cab at low speed over bumps, visible gap changes between the cab and bed, and cab movement relative to the frame during hard acceleration or braking. Inspecting the mounts directly by lifting the vehicle and checking for cracking, compression, or missing chunks of rubber is the most reliable confirmation method.

Energy Suspension's Hyper-Flex compound for body mounts is formulated with a softer durometer than their suspension bushings to preserve ride compliance. On a properly installed set, cab noise and vibration transmission should remain comparable to new OEM mounts. NVH increase over worn rubber mounts is normal, since worn mounts are compressively compliant in ways new mounts are not. The polyurethane is not as compliant as new OEM rubber, so minor increases in vibration transmission are possible depending on engine mount condition and road surface.

Yes. The 5.4117R is a complete body mount set covering all cab mounting positions on the 2009-2018 Ram 1500 Extended Cab and Crew Cab. It is not sold as a single mount. Confirm the total count required for your specific cab configuration in the Energy Suspension application guide before ordering.

Energy Suspension recommends applying their supplied or compatible polyurethane-safe grease to bushing contact surfaces during installation to prevent squeaking. Do not use petroleum-based greases, as they degrade polyurethane over time. Energy Suspension's own formula or a white lithium grease compatible with polyurethane are the standard choices.

Body lift kits use their own dedicated puck-style spacers rather than factory-style body mounts. The ENG5.4117R is designed as a factory-position body mount replacement, not as a body lift component. It can be used in conjunction with a body lift spacer stack in some configurations, but fit and application compatibility depend on the specific lift kit design. Confirm with your body lift manufacturer before ordering.

Yes. The Energy Suspension 5.4117G and 5.4117R are the same body mount set in different colors. G designates black and R designates red. The polyurethane compound, construction, and fitment are identical. Color selection is purely aesthetic.

Installation Instructions

1. Lift and safely support the Ram 1500 on jack stands at the frame rails, with the suspension hanging free.
2. Identify all factory body mount locations along the cab perimeter. Photograph mount positions before removal for reference during reassembly.
3. Using an appropriate socket and extension, remove the body mount bolts from the top of the cab floor. Note that some bolts may be accessed from inside the cab through floor plugs.
4. Carefully raise the cab slightly using a floor jack under a padded contact point to relieve pressure from the mount being removed. Work one mount at a time.
5. Remove the factory rubber mount and retain any steel cups, sleeves, or washers that are not included in the Energy Suspension kit.
6. Apply Energy Suspension polyurethane-safe grease to the inside bore of the new ENG5.4117R bushing and to the mount bolt shoulder.
7. Install the new polyurethane bushing into position with the steel insert ring oriented correctly per the original mount design.
8. Lower the cab back onto the new mount and install the mounting bolt hand-tight. Repeat for all remaining mounts before final torque.
9. With all mounts installed hand-tight, torque all body mount bolts to factory specification in a cross pattern to ensure even seating.
10. Lower the vehicle and visually confirm cab-to-bed alignment before driving.
