GSC P-D 12+ Subaru BRZ / Scion FR-S Single Spring Chromoly Seat and Titanium Retainer Kit GSC Power Division GSC5756
GSC P-D 12+ Subaru BRZ / Scion FR-S Single Spring Chromoly Seat and Titanium Retainer Kit GSC Power Division GSC5756
Click to zoom in

GSC P-D 12+ Subaru BRZ / Scion FR-S Single Spring Chromoly Seat and Titanium Retainer Kit

GSC5756
GSC5756
Valve Springs, Retainers
20+ Units In Stock - Ships Next Business Day
$ 360.01 $ 306.01
$ 306.01

SKU: 5756 | UPC: GSC5756

GSC Power-Division 2013+ Subaru BRZ / Scion FR-S / Toyota 86 Single Spring Chromoly Seat and Titanium Retainer Kit

This GSC Power-Division kit upgrades the valvetrain on 2013 and later Subaru BRZ Scion FR-S and Toyota 86 FA20 engines with single spring Chromoly steel seats and Titanium retainers. It handles higher engine speeds through precise spring rates and lower rotating mass for reliable valve control. Drivers achieve consistent performance in prolonged high rev sessions without spring fatigue or failure.

Key Features

  • Titanium Retainers: Weigh 10 grams each cutting valvetrain mass by over 18 grams per valve versus stock for faster revving and less inertia
  • Chromoly Steel Seats: Deliver high strength and durability to manage elevated seat pressures without distortion under heavy loads
  • Single Spring Design: Provides 65 lbs seat load at 1.680 inches and 180 lbs open load at 1.000 inch lift with 0.513 inch maximum lift capacity
  • Coil Bind Height: At 1.130 inches allows safe operation to 10,500 RPM fully compatible with aftermarket cams
  • Complete Kit: Contains 16 springs 16 Titanium retainers and 16 Chromoly seats for direct replacement on FA20 engines

Product Notes

  • Valve seals must be replaced during installation for proper sealing
  • Inspect retainers and seats for correct orientation during assembly
  • Kit ships in protective foam packaging to prevent damage

Installation Notes

  • Professional installation recommended.
  • Remove stock valvetrain components and measure installed height before fitting
  • Compatible with OEM and most aftermarket valve locks no special hardware needed

This Part Fits

Year Make Model Submodel
2013-2016 Scion FR-S Base
2013-2017 Subaru BRZ Limited
2013-2017 Subaru BRZ Premium
2013-2020 Subaru BRZ All FA20
2015 Subaru BRZ Series.Blue
2016 Subaru BRZ Series.HyperBlue
2017-2020 Toyota 86 Base
2017 Toyota 86 Special Edition
2017-2020 Toyota 86 All FA20

Why Choose GSC Power-Division?

  • Engineered and manufactured in the USA with focus on motorsport valvetrain reliability
  • Dyno tested for consistent performance across thousands of RPM cycles
  • Backed by real-world racing data from drag and circuit applications

Frequently Asked Questions

  • Q: Will this kit fit 2013-2020 Toyota 86 and Subaru BRZ models?
    A: Yes it directly replaces OEM valvetrain on all FA20 powered 2013+ Scion FR-S Subaru BRZ and Toyota 86 variants listed in fitment
  • Q: What materials are used in the retainers and seats?
    A: Retainers are aerospace grade Titanium for lightweight strength seats are heat treated Chromoly steel for maximum durability
  • Q: Does installation require any modifications?
    A: No modifications needed includes all parts for drop-in install though professional setup ensures proper spring height

Shipping & Handling

  • Method: UPS Ground or USPS Priority
  • Availability: In stock - ships same or next business day
  • Packaging: Compact box measuring 6 x 6 x 4 inches
  • Weight: 2.0 lbs
