SKU: 22-89-1000
PDS 8HP70 Transmission Pan - AWD for 2014-2019 BMW X5 X6 xDrive
The PDS 8HP70 Transmission Pan - AWD is a cast aluminum deep sump designed for ZF 8HP70 transmissions in AWD BMW X5 and X6 models. It holds 3 extra quarts of fluid to reduce operating temperatures and improve lubrication during spirited driving. This pan captures debris and manages fluid flow for reliable shifts and extended transmission life.
Key Features
- Increased Capacity: Adds 3 quarts over stock for lower fluid temps and consistent pressure in high-load conditions
- Cooling Fins: Large external fins increase surface area to shed heat 40 percent faster than OEM pan
- Neodymium Magnet: Powerful removable magnet traps metal particles to prevent wear on clutches and gears
- Anti-Slosh Baffles: Internal baffles direct fluid flow and prevent starvation in corners or launches
- Hardware Included: Comes with gasket, magnetic drain plug, bolts, and washer for direct bolt-on install
Product Notes
- Flush transmission fluid recommended at install for best results
- Works with OEM transmission filter and service procedures
- Ground shipping only due to size and weight
Installation Notes
- Professional installation recommended.
- Drain fluid before removing stock pan. support transmission if needed
- Bolts torque to 10 Nm. verify gasket seating to avoid leaks
This Part Fits
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2014-2018 | BMW | X5 | xDrive35i, xDrive40i, xDrive50i |
| 2015-2019 | BMW | X6 | xDrive35i, xDrive40i, xDrive50i |
| 2014-2018 | BMW | X5 | xDrive30d, xDrive40d, M50d |
| 2015-2019 | BMW | X6 | xDrive30d, xDrive40d, M50d |
| 2013-2017 | BMW | 5 Series | 535d xDrive Sedan, Wagon |
| 2014-2018 | BMW | 6 Series | 640i xDrive Gran Coupe |
Why Choose PDS?
- Engineered specifically for ZF 8HP transmissions in BMW xDrive vehicles
- Cast A356-T6 aluminum construction with wrinkle black powder coat finish
- Direct OEM replacement with enhanced capacity and debris control
Frequently Asked Questions
-
Q: Does this pan fit 2016 BMW X5 xDrive40i F15?
A: Yes, it bolts directly to the ZF 8HP70 AWD transmission in all 2014-2018 F15 X5 xDrive models -
Q: What material and finish does the pan have?
A: Made from durable A356-T6 cast aluminum with textured black powder coat for corrosion resistance and heat management -
Q: Is a warranty included and what about install?
A: Backed by PDS limited lifetime warranty. professional install advised to ensure proper torque and fluid fill
Shipping & Handling
- Method: UPS Ground
- Availability: In stock - ships same or next business day
- Packaging: Sturdy cardboard box 22 x 14 x 6 inches
- Weight: 14 lbs
