QA1 70-81 GM F Body Four Link Kit Stage 1 Double Adjustment - Primary
QA1 70-81 GM F Body Four Link Kit Stage 1 Double Adjustment - Close Up
QA1 70-81 GM F Body Four Link Kit Stage 1 Double Adjustment - Close Up
QA1 70-81 GM F Body Four Link Kit Stage 1 Double Adjustment - Close Up
QA1 70-81 GM F Body Four Link Kit Stage 1 Double Adjustment - Close Up
QA1 Four Link Suspension Kit 1970-1981 GM F-Body – Stage 1 Double Adjustable  - Close Up
Click to zoom in

QA1 70-81 GM F Body Four Link Kit Stage 1 Double Adjustment

QA1
QAPR257-170
806990175571
Suspension Packages
Out of stock
$ 2,878.11 $ 2,597.95

SKU: R257-170 | UPC: 806990175571

QA1 Four Link Suspension Kit 1970-1981 GM F-Body – Stage 1 Double Adjustable

QA1 R257-170 Four Link Suspension Kit fits 1970-1981 Chevrolet Camaro and Pontiac Firebird models. This triangulated 4-link system with double adjustable coilovers replaces leaf springs for precise control over rebound and compression damping. It provides adjustable ride height from +2 to -3 inches, supports wide wheels up to 12 inches and 335mm tires with mini-tubs, and installs with minimal welding.

Key Features

  • Triangulated 4-Link Design: Tubular bars ensure strength and geometry for consistent handling on street, track, or drag strip with independent 18-click rebound and compression tuning.
  • Adjustable Ride Height: Set from 10.75-12 inches on Camaro or 13.75-15 inches on Firebird (axle centerline to fender arch) for lowered stance and optimized roll center.
  • Wide Wheel Compatibility: Clears up to 12-inch wheels and 335mm tires in mini-tub setups for better traction and aggressive look.
  • Bolt-On Installation: Brackets and hardware included, no floor pan cuts needed, easy pinion angle and wheelbase adjustments without link removal.
  • Built for Durability: Made in USA with lifetime warranty on Proma Star shocks when registered at QA1.net/warranty, handles high power and aggressive use.

Product Notes

  • QA1 subframe connectors recommended for chassis stiffness.
  • Exhaust modifications may be required, not compatible with over-axle pipes.
  • Weight 68 lbs, verify wheel and tire fitment before install.

Installation Notes

  • Professional installation recommended.
  • Welding required for brackets, detailed instructions provided.
  • Includes all mounting hardware, spanner wrench, and brackets for direct fit.

This Part Fits

Year Make Model Submodel
1970-1980 Chevrolet Camaro Base
1979-1981 Chevrolet Camaro Berlinetta
1973-1978 Chevrolet Camaro LT
1976-1978 Chevrolet Camaro LT Rally Sport
1976-1980 Chevrolet Camaro Rally Sport
1970-1973 Chevrolet Camaro RS
1975 Chevrolet Camaro RS
1981 Chevrolet Camaro Sport
1970-1972 Chevrolet Camaro SS
1970-1974 Chevrolet Camaro Z28
1977-1981 Chevrolet Camaro Z28
1970-1981 Pontiac Firebird Base
1970-1981 Pontiac Firebird Esprit
1970-1981 Pontiac Firebird Formula
1970-1981 Pontiac Firebird Trans Am

Why Choose QA1?

  • American-made in Lakeville, Minnesota for reliable quality.
  • Double adjustable Proma Star shocks with 18 settings each for track-ready damping.
  • Complete kit with lifetime shock warranty and precise engineering.

Frequently Asked Questions

  • Q: What ride heights does this kit support?
    A: Camaro 10.75 to 12 inches, Firebird 13.75 to 15 inches from axle centerline to fender arch, adjustable in 0.25-inch increments.
  • Q: Does it require mini-tubs for wide tires?
    A: Yes for maximum 335mm tires and 12-inch wheels, standard tubs work for narrower setups.
  • Q: What warranty is included?
    A: Lifetime on shocks with online registration at QA1.net/warranty, covers defects under normal use.

Shipping & Handling

  • Method: UPS Ground or Freight for heavy items
  • Availability: In stock - ships same or next business day
  • Packaging: Ships in one oversized box, approximately 48 x 12 x 12 inches
  • Weight: 68 lbs
