Four Longer Front U-Bolts Sized for a Lifted YJ Spring Pack
Tuff Country 47800 is a four-piece front axle U-bolt kit for the 1987-1996 Jeep Wrangler, aimed at trucks running a lift where the factory U-bolts no longer reach around the pack. All four are 1/2 in round-bend U-bolts, zinc plated, and the set deliberately mixes two inside diameters and two lengths to suit the front spring seats.
Key Features
- Front axle U-bolt kit engineered for lift-kit-equipped vehicles rather than stock replacement duty.
- Zinc plated for corrosion resistance.
- Set of four U-bolts supplied complete with nuts and washers.
- Mixed-size set: two at 2.5 in inside diameter and two at 3 in inside diameter to suit the front spring pack.
- Two lengths supplied, 7 in and 7.75 in, all in a round-bend style.
- 1/2 in bolt diameter across the set, sold as a complete kit rather than as singles.
Fitment
| Vehicle | Application |
|---|---|
| Jeep Wrangler | 1987-1996, front axle |
Submodel-level data behind this kit covers the Islander, Laredo, Renegade, Rio Grande, S, SE, Sahara and Sport variants within the 1988-1995 window, all of which sit inside the 1987-1996 Wrangler range on the tag.
Specifications
| Detail | Value |
|---|---|
| Brand | Tuff Country |
| MPN | 47800 |
| Part type | Front axle U-bolt kit |
| Quantity | 4 U-bolts |
| Bolt diameter | 1/2 in |
| Inside diameter | 2.5 in on two, 3 in on two |
| Length | 7 in on two, 7.75 in on two |
| Bend type | Round on all four |
| Material | Steel |
| Finish | Zinc plated |
| Axle position | Front |
What's Included
- Four Tuff Country U-bolts, two at 2.5 in ID and two at 3 in ID
- Nuts for all four U-bolts
- Washers for all four U-bolts
About Tuff Country
Tuff Country builds suspension lifts for solid-axle trucks and Jeeps, and it sells the consumable hardware that those lifts need as separate kits. This U-bolt set exists because a lifted YJ front pack, especially one with an added leaf or a block, needs a longer clamp than the factory U-bolt, and because reusing stretched U-bolts on a front axle is poor practice.
FAQ
Why does the set mix two different inside diameters?The front spring seats on the YJ do not present an identical stack at every position, so the kit supplies two 2.5 in ID U-bolts and two 3 in ID U-bolts rather than four identical parts.
Is this kit for a stock Wrangler or a lifted one?It is aimed at vehicles running a lift kit, which is where the longer 7 in and 7.75 in lengths become necessary.
Does one kit do the whole front axle?Yes. Four U-bolts is the full front axle count on a leaf-sprung YJ, two per side.
Are nuts and washers included, or do I reuse the old ones?New nuts and washers come with the kit, and reusing old U-bolt nuts on a front axle is not worth the risk.
What thread size are the U-bolts?They are 1/2 in diameter.
Are these bent square or round?All four are round-bend U-bolts.
What torque should they be tightened to?No torque value is published for this kit, so use the figure given in the instructions for the lift kit or spring pack the U-bolts are clamping.
Will the zinc plating hold up to salt?Zinc plating is applied for corrosion resistance, and it will last considerably longer if the threads are kept clean and the assembly is rinsed after winter driving.
Can these be used on the rear axle instead?The kit is specified as a front axle set. Rear U-bolt lengths and diameters differ, so use the rear-specific part rather than assuming the fronts will fit.
Installation Instructions
- Support the Jeep on stands under the frame and take the load off the front leaf springs before loosening anything.
- Remove the old U-bolts one side at a time so the axle stays located by the other side while you work.
- Compare each new U-bolt against the seat it is going into, since the kit deliberately supplies two inside diameters and two lengths.
- Check the spring pack, centre pin and spring plate for damage while everything is apart.
- Fit the correct U-bolt over the axle and through the plate, keeping the legs parallel and the bend fully seated.
- Start the supplied nuts and washers by hand on clean threads.
- Tighten in an alternating pattern so the spring plate pulls down evenly, using the torque figure from the lift kit instructions.
- Lower the Jeep, roll it back and forth to settle the suspension, then re-check every nut after the first drive and again after a few hundred miles.
