Vossen HFX-5 - 20x9.5 - 6x139.7 - ET30 - Deep Face - 106.1 - Gloss Black Wheel

The Vossen HFX-5 is a 6-lug Hybrid Forged wheel built on Vossen's flow forming platform, designed specifically for 6-lug light trucks, SUVs, and full-size pickup trucks. The HFX-5 uses a multi-spoke face design with an aggressive deep concave profile that fills the fender well on lifted and leveled trucks, providing a fitment-forward look that sets it apart from standard cast truck wheels. Each HFX-5 is manufactured using Vossen's flow forming process, which produces a stronger and lighter barrel than conventional casting by stretching and compressing the aluminum barrel material through hydraulic pressure rollers after the initial cast. The result is a barrel with improved grain structure and higher tensile strength, approaching the properties of a fully forged wheel at a significantly lower cost.

Hybrid Forged Flow Forming Process

The HFX-5 begins as a gravity-cast aluminum face. After casting, the wheel is mounted to a flow forming drum, and heat is applied to the barrel section. Hydraulic rollers then stretch and compress the barrel material radially, elongating the grain structure along the axis of stress. This process produces a barrel that is measurably denser, stronger, and lighter than a conventionally cast barrel of the same dimension. Vossen's flow forming equipment allows the process to be applied to a range of barrel widths within the same face design, which is how the HFX-5 is available in multiple offsets and widths from 20 to 22 inches across different bolt pattern families without requiring separate tooling for each size combination.

Deep Concave Profile

The HFX-5 is offered in a Deep concave profile across the available sizes. The deep concave profile positions the face of the wheel significantly inboard relative to the outer lip, creating a pronounced three-dimensional depth that is especially visible on trucks with wider-than-stock tires. The deep profile maximizes brake caliper clearance on vehicles running large aftermarket brake kits. Combined with the 9.5-inch width available across both 20-inch and 22-inch diameters, the HFX-5 provides adequate fitment width for 285 to 305-width tires commonly paired with 6-lug light truck applications.

6x139.7 Bolt Pattern Fitment

The HFX5-0G01-30 is built on the 6x139.7 bolt pattern, which covers the core GM 1500-series truck and SUV platform as well as Toyota full-size and mid-size applications. Compatible vehicles include the Chevrolet Silverado 1500, GMC Sierra 1500, Chevrolet Tahoe, Chevrolet Suburban, GMC Yukon, GMC Yukon XL, Cadillac Escalade, Toyota Tundra, Toyota 4Runner, Toyota FJ Cruiser, Nissan Titan, Lexus GX, and Land Cruiser series. The center bore on this size is 106.1mm. Hub centric rings are recommended when the vehicle's hub bore is smaller than 106.1mm to ensure proper wheel centering. The ET30 offset on this size is a medium-forward positioning that works well with both factory and mildly lifted suspension setups.

Gloss Black Finish

The HFX5-0G01-30 is finished in Gloss Black. The Gloss Black finish is a high-sheen solid black applied after flow forming and face machining to ensure consistent coverage across spoke faces, lips, and the barrel. Gloss Black reads cleanly on both dark and light-colored truck body colors. It contrasts well with chrome and polished brake hardware, and pairs with a wide range of exterior colors from white and silver to red and blue. All finishes are applied after structural processing is complete to maintain uniform adhesion and coverage across the wheel profile. Center caps are included with each wheel.

Warranty

Vossen backs the HFX-5 with a five-year workmanship warranty and a lifetime structural warranty. The five-year workmanship warranty covers finish defects and quality issues. The lifetime structural warranty covers the wheel barrel and face against defects in the flow forming and casting process for the life of original ownership. These warranties are among the most comprehensive in the aftermarket wheel segment. Proof of purchase and installation records are required to initiate any warranty claim through Vossen directly.

What's Included

• 1 x Vossen HFX5-0G01-30 wheel (single)
• 1 x Vossen center cap
• Vossen valve stem cap

Note: Lug nuts, tires, TPMS sensors, and hub centric rings are not included. Prices shown are per wheel. Sold individually.

Product Specifications

Frequently Asked Questions

Does the Vossen HFX5-0G01-30 fit a 2019 Chevrolet Silverado 1500?
Yes. The 2019 Chevrolet Silverado 1500 uses a 6x139.7 bolt pattern. The HFX5-0G01-30 is built on the 6x139.7 pattern with a 106.1mm center bore. The Silverado 1500 hub bore is 78.1mm, so a set of 78.1mm-to-106.1mm hub centric rings is needed to properly center the wheel. With hub rings installed, the HFX5-0G01-30 fits the 2019 Silverado 1500. Verify offset clearance using a wheel fitment calculator with your suspension setup and tire choice.

What Toyota vehicles fit the HFX5-0G01-30?
The 6x139.7 bolt pattern on the HFX5-0G01-30 fits the Toyota Tundra (all generations), Toyota 4Runner (all generations), Toyota FJ Cruiser, and third-generation Toyota Tacoma with the 6-lug configuration. Lexus GX models also use 6x139.7. Confirm center bore and offset compatibility for your specific year and trim before ordering.

What is the difference between ET30 and ET20 on the HFX-5?
On the 20x9.5 HFX-5, ET30 positions the face 30mm from the wheel centerline toward the front of the vehicle, while ET20 pushes the face 20mm out, resulting in a more outboard wheel position. ET30 typically tucks slightly more under the fender than ET20. If you are running a leveling kit or a lift of 2 to 3 inches, ET20 can give a more aggressive stance. ET30 is generally safer for stock and mildly modified trucks where fender clearance is tighter.

Does the HFX-5 come with lug nuts?
No. Lug nuts are not included. The HFX5-0G01-30 requires seat-style lug nuts appropriate for your vehicle's lug nut thread pitch and seat angle. Most GM 6-lug applications use 14mm x 1.5 thread pitch with a conical seat. Check your vehicle's service specifications for the correct thread pitch and seat type before purchasing lug hardware separately.

Is the Vossen HFX-5 heavier than a forged wheel?
The HFX-5 is heavier than a fully forged monoblock wheel of the same size, but lighter than a conventionally cast wheel. The flow forming process used on the barrel reduces weight by stretching the material thinner than conventional casting while improving structural integrity. The face remains cast, which carries more mass than a forged face. For most street and mild off-road applications on light trucks, the HFX-5's weight is comparable to OEM alloy wheels and represents a meaningful improvement over entry-level cast aftermarket wheels.

Can I run a 285/55R20 tire on the Vossen HFX5-0G01-30?
A 285/55R20 tire on a 20x9.5 rim is within the tire manufacturer's recommended rim width range for most 285-width tires. The combination is mechanically compatible. Whether it clears your specific vehicle's fenders, suspension components, and wheel well liner at full lock and full compression depends on your vehicle's geometry, lift height, and trim level. Use a wheel offset and backspacing calculator with your vehicle specifications before confirming fitment.

Is the HFX-5 20x9.5 6x139.7 ET30 compatible with a Nissan Titan?
The Nissan Titan uses a 6x139.7 bolt pattern, which matches the HFX5-0G01-30. The Titan hub bore is typically 78.1mm. With 78.1mm-to-106.1mm hub centric rings, the HFX5-0G01-30 will center properly on the Titan hub. Confirm the offset and backspace work with your Titan's specific configuration and any suspension modifications before ordering.

What is Vossen's lifetime structural warranty?
Vossen's lifetime structural warranty covers the original purchaser against structural defects in the wheel barrel and face caused by defects in materials or the flow forming manufacturing process. It does not cover damage from impact, road hazard, improper installation, curb rash, or use in racing or off-road motorsports competition. The five-year workmanship warranty covers finish quality including peeling, bubbling, or abnormal fading not caused by chemical contact or abrasion. Both warranties are non-transferable and require proof of purchase.
