Vossen HFX-5 - 22x9.5 - 6x139.7 - ET20 - Deep Face - 106.1 - Satin Bronze Wheel

The Vossen HFX-5 is a 6-lug Hybrid Forged wheel built on Vossen's flow forming platform, designed specifically for 6-lug light trucks, SUVs, and full-size pickup trucks. The HFX-5 uses a multi-spoke face design with an aggressive deep concave profile that fills the fender well on lifted and leveled trucks. Each HFX-5 is manufactured using Vossen's flow forming process, which produces a stronger and lighter barrel than conventional casting by stretching and compressing the aluminum barrel material through hydraulic pressure rollers after the initial cast.

Hybrid Forged Flow Forming Process

The HFX-5 begins as a gravity-cast aluminum face. After casting, the wheel is mounted to a flow forming drum, and heat is applied to the barrel section. Hydraulic rollers then stretch and compress the barrel material radially, elongating the grain structure along the axis of stress. This produces a barrel that is measurably denser, stronger, and lighter than a conventionally cast barrel of the same dimension. The result approaches the properties of a fully forged barrel at a lower cost.

Deep Concave Profile

The HFX-5 is offered in a Deep concave profile. The deep profile positions the face of the wheel significantly inboard relative to the outer lip, creating pronounced three-dimensional depth especially visible on trucks with wider-than-stock tires. It also maximizes brake caliper clearance on vehicles running large aftermarket brake kits.

6-Lug Truck Platform Compatibility

This listing is for the HFX-5 in 22x9.5, 6x139.7, ET20, 106.1mm center bore. The 6x139.7 bolt pattern fits GM 1500-series trucks (Silverado, Sierra), Toyota Tundra, Toyota 4Runner, FJ Cruiser, Nissan Titan, Lexus GX, and Land Cruiser applications. Hub centric rings are recommended when the vehicle hub bore does not match 106.1mm. This wheel does not include lug nuts, tires, or TPMS sensors.

Finish: Satin Bronze

Satin Bronze is a warm-tone metallic finish that pairs well with earth-toned and neutral truck body colors. The finish is applied after flow forming and face machining for consistent coverage across all spokes, lips, and barrel surfaces.

What's Included

• 1 x Vossen HFX-5 wheel in 22x9.5, 6x139.7, ET20, Satin Bronze (single)
• 1 x Vossen center cap
• Vossen valve stem cap

Note: Lug nuts, tires, TPMS sensors, and hub centric rings are not included. Sold individually.

Product Specifications

Frequently Asked Questions

Does the Vossen HFX-5 in 6x139.7 fit a 2019 GMC Sierra 1500?
Yes, with hub centric rings. The Sierra 1500 uses a 78.1mm hub bore. The HFX-5 has a 106.1mm bore. You need 78.1-to-106.1mm rings to center the wheel correctly. With rings, the HFX-5 in 6x139.7 bolts on properly.

Does the HFX-5 come with lug nuts?
No. Purchase seat-style lug nuts to match your vehicle. GM 6-lug applications typically use 14mm x 1.5 conical-seat lug nuts.

What tire width fits on a 22x9.5 HFX-5?
The 9.5-inch rim is compatible with 275 through 305-width tires for most applications. A 285/45R22 or 295/40R22 is a common pairing. Confirm clearance for your specific vehicle suspension and lift height.

What is the difference between the HFX-5 and the HF6-5?
The HFX-5 is Vossen's current-generation 6-lug Hybrid Forged wheel. The HF6-5 is the previous generation. Both use flow forming, but the HFX-5 has revised spoke geometry with deeper pockets for improved brake ventilation.

Is the HFX-5 TPMS compatible?
Yes. The HFX-5 is compatible with standard TPMS sensors. Sensors are not included and must be transferred from your OEM wheels or purchased separately.

What is Vossen's lifetime structural warranty?
Vossen's lifetime structural warranty covers structural defects in the barrel and face due to manufacturing defects for original purchaser. It does not cover impact damage, curb rash, or racing use. The separate 5-year workmanship warranty covers finish quality issues.

Does the satin bronze finish fade or oxidize over time?
Satin Bronze is a powder coat finish. It resists fading and oxidation under normal use. Avoid harsh acid-based wheel cleaners and abrasive pads. Mild soap and water or a pH-neutral wheel cleaner keeps the finish in good condition.

Can I use these on a lifted truck?
Yes. The deep concave profile and 9.5-inch width are well suited to lifted trucks running 285 to 305-width tires. Confirm backspacing using a fitment calculator with your lift height, tire width, and vehicle model before ordering.
