SKU: 254-334
Airaid Performance intake system CTS-V
The AIRAID Cold Air Dam (CAD) Air Intake is engineered to give your engine larger amounts of cooler air to produce more horsepower and torque. The intake system retains the original location of the air filter but delivers a big boost with the addition of a huge open-element air inlet protected by Cold Air Dam panels that help to provide a steady, free-flowing supply of cooler outside air into your engine. The panels mount in the factory air box location and utilize any factory cold air inlet ducts that are present, while adding additional cold air passages to the filter. The panels also keep the filter isolated from the hot engine compartment air by sealing to the underside of the hood via blade-style weather stripping. This CAD system utilizes a replacement low-restriction intake tube. The 360-degree conical AIRAID premium air filter is washable and reusable, less restrictive than traditional paper, and assures superior filtration. The AIRAID Cold Air Dam Air Intake is easy to install with common hand tools. Increases horsepower and torque
- Increases horsepower and torque
- Replaces stock air box, air filter and intake tubing
- Cold Air Dam panels block out hot engine bay air
- Easy to install using commonly available tools
- Easy to clean oil-free synthetic air filter
- Washable and reusable air filter media
SPECIFICATIONS
|
Estimated Horsepower Gain |
31.1 HP @ 4645 RPM |
|
Replacement Filter |
704-505 |
|
Air Filter Color |
Yellow |
|
Air Filter Material |
Non-woven Synthetic |
|
Clamps Included |
3 |
|
Clamp Material |
Stainless Steel |
|
Clamp Style |
Worm Gear |
|
Couplers Included |
1 |
|
Product Style |
AIRAID Intake Kit |
|
Air Filter Outlet Shape |
Round |
|
Intake Pipe Color / Finish |
Black |
|
Intake Pipe Material |
High-Density Cross-Linked Polyethylene |
|
Street Legal In All US States |
Not legal for sale or use in California on any pollution controlled motor vehicle. |
|
TUV Approved (Europe) |
No |
|
Weight |
3.9 lb (1.8 kg) |
|
Product Box Height |
15.5 in (394 mm) |
|
Product Box Length |
19.75 in (502 mm) |
|
Product Box Width |
15.88 in (403 mm) |
|
California Restricted |
Not legal for sale or use in California |
|
Mounting Hardware Included |
Yes |
|
Warranty |
No-Hassle Lifetime Limited |
VEHICLE APPLICATIONS
2016-2019 Cadillac CTS-V 6.2L V8 Gas
