Build the Core of a Verified 4 Inch Radius Arm System
FTS22215 is the basic system component box used in Fabtech 4 inch radius arm systems for 2017-2022 Ford F-250 and F-350 Super Duty 4WD trucks. This is not a complete lift kit. The correct front coil box, rear box kit, and Fabtech shocks must be purchased separately for the selected gas, diesel, or coilover system configuration.
Key Features
- Designed as the core steering, radius arm, and bracket package for supported FTS22215 system configurations
- Includes driver and passenger radius arms, a pitman arm, a track bar drop bracket, sway bar drops, bump stop extensions, and steering stabilizer mounting components
- Supports gas and diesel applications when paired with the correct engine specific coil box
- Requires Fabtech shock absorbers and the remaining boxes specified for the selected complete system
- Intended for non dually 4WD trucks
Fitment
| Year | Make | Model | Drivetrain | Application Notes |
|---|---|---|---|---|
| 2017-2022 | Ford | F-250 Super Duty | 4WD | Non dually models. Requires the correct additional Fabtech system components. |
| 2017-2022 | Ford | F-350 Super Duty | 4WD | Non dually models. Requires the correct additional Fabtech system components. |
Specifications
| Detail | Value |
|---|---|
| Brand | Fabtech |
| Manufacturer Part Number | FTS22215 |
| Product Type | 4 inch radius arm system component box |
| Vehicle Position | Front suspension and steering |
| Package Scope | One basic system component box only |
| UPC | 674866102811 |
| Not Included | Front coil springs, rear block and U bolt kit, and shock absorbers |
What's Included
- One FTS22215 basic system component box
- One pitman arm
- Two 4 inch bump stop extensions
- One driver side radius arm and one passenger side radius arm
- One track bar drop bracket
- One hardware kit
- One hardware subassembly with instructions, sector shaft nut, brake line tabs, bump stop nut tabs, spacer, decals, registration card, bushings, sleeves, alignment cam kit, and urethane lubricant
- One steering stabilizer bracket and one steering stabilizer clevis mount
- One driver side sway bar drop and one passenger side sway bar drop
About Fabtech
Fabtech develops vehicle specific suspension systems and publishes application based parts lists and installation instructions. Its system approach requires the specified Fabtech boxes and shocks to be used together rather than mixing unmatched suspension components.
Related Parts
FAQ
What is the FTS22215?It is the basic component box that supplies the radius arms, steering and suspension relocation brackets, bump stop extensions, and installation hardware for compatible Fabtech 4 inch systems.
Is this a complete 4 inch lift kit?No. This component box does not include front coil springs, the rear box kit, or shock absorbers. Those parts must match the selected Fabtech system configuration.
Which trucks does this component box fit?It is used on 2017-2022 Ford F-250 and F-350 Super Duty 4WD trucks in the listed Fabtech radius arm systems.
Can it be used on both gas and diesel trucks?Yes, the core component box is shared. Gas and diesel trucks require different front coil boxes, so the coil package must match the engine application.
Does it fit dually models?No. The application is specified for non dually models.
Are shock absorbers included?No. Fabtech shock absorbers are required and must be selected according to the complete system configuration.
What additional boxes are normally required?Standard coil spring configurations require the applicable gas or diesel front coil box, the specified rear box kit, and the specified front and rear Fabtech shocks. Coilover configurations use a different matching parts list.
Who should install this component box?Fabtech specifies installation by two professional mechanics. The work requires vehicle support equipment, drilling and cutting tools, a torque wrench, and a front end alignment.
What warranty applies?Fabtech provides a Limited Lifetime Warranty to the original retail purchaser who owns the vehicle for defects in workmanship and materials. Wear items, finish, improper installation, alterations, commercial use, racing, and mixed aftermarket suspension systems are excluded or have separate limits.
What tire and wheel guidance is published for the complete system?Fabtech lists 35/12.50R18 tires on 18 by 9.5 wheels with 4.75 inches of backspacing, or 35/12.50R20 tires on 20 by 9 wheels with 5 inches of backspacing. Fenderwell, bumper, or valance trimming may be required.
Installation Instructions
- Confirm that FTS22215 is being combined with the correct coil box, rear box, and Fabtech shock package for the vehicle and selected system.
- Read the complete Fabtech installation instructions and verify every component before work begins.
- Check the vehicle for frame or suspension damage and record a factory specification front end alignment before installation.
- Have two professional mechanics perform the installation with the vehicle safely supported.
- Use the specified hand tools, sockets, torque wrench, drill, cutting tool, and 1.25 inch hole saw.
- Apply the supplied thread locking compound and follow every published torque and safety requirement.
- After installation, align the front end, check differential fluid, inspect tire clearance, and readjust the headlights.
- Recheck all nuts, bolts, and lug nuts after 50 miles and inspect them periodically thereafter.
