MaxTrac 04-17 Ford F-150 2WD 5-6in Rear Shock Absorber

Twin-Tube Gas Rear Shock for Lowered 2004 Through 2017 Ford F-150 2WD

The MaxTrac 2200LL-9 is a single twin-tube gas-charged rear shock absorber designed for the 2004 through 2017 Ford F-150 two-wheel drive with a 5 to 6-inch rear drop. The MaxTrac 2200LL-9 uses a loop-over-loop mount configuration with an extended length of 22.30 inches and a collapsed length of 13.40 inches to properly match the geometry of a 5 to 6-inch lowered F-150 rear suspension. The 2200LL-9 includes two 0.4375-inch steel sleeves and all necessary hardware and must be installed with the shock shaft oriented toward the top. Sold individually. The 2200LL-9 provides fade-free performance and improved ride quality on a lowered 2WD F-150 where stock-length shocks are incompatible with the drop.

Why the F-150 Needs Drop-Specific Shocks

When you lower a 2004 through 2017 Ford F-150 2WD with spindles, a flip kit, or drop shackles, the factory-length rear shock absorbers become fully extended at the new ride height. Driving on a stock-length shock in a lowered application causes the shock to bottom out, eliminates dampening travel, and results in a harsh, uncontrolled ride. The MaxTrac 2200LL-9 is built specifically for the 5 to 6-inch drop range, with extended and collapsed lengths that provide correct shock travel at the lowered ride height. Gas-charged twin-tube construction provides consistent dampening performance across varying road conditions.

What's Included

• 1 x MaxTrac 2200LL-9 rear shock absorber
• 2 x 0.4375-inch steel sleeves
• Installation hardware

Specifications

Fitment

Frequently Asked Questions

Does the MaxTrac 2200LL-9 fit 4WD F-150 models?
The 2200LL-9 is designed for two-wheel drive F-150 trucks. Some MaxTrac sources reference this shock for both 2WD and 4WD applications in select year ranges. Confirm your specific year and drivetrain fitment with MaxTrac directly before ordering.

How many 2200LL-9 shocks do I need for a complete rear install?
The 2200LL-9 is sold individually. You need two units to replace both rear shocks on your F-150. Order two if you are doing a complete rear shock replacement.

What drop kits use the MaxTrac 2200LL-9?
The 2200LL-9 is commonly used as part of the MaxTrac rear lowering package for the F-150, including spindle-and-flip-kit combinations that produce 5 to 6 inches of total rear drop. It is also sold as a replacement shock for trucks already running that drop range.

Why must the MaxTrac 2200LL-9 shaft face upward?
MaxTrac's twin-tube gas shock requires the piston rod to be oriented toward the top of the mount for proper gas charge function and fluid distribution. Installing the 2200LL-9 with the shaft facing down will cause oil aeration, premature wear, and loss of dampening performance.

Does the MaxTrac 2200LL-9 come with mounting hardware?
Yes. The 2200LL-9 includes two 0.4375-inch steel sleeves and all required installation hardware.

Will the MaxTrac 2200LL-9 improve ride quality compared to a stock shock at drop height?
Yes. The 2200LL-9 is purpose-built for the 5 to 6-inch drop range, providing proper shock travel at the correct ride height. A stock-length shock at this drop height is near full extension at rest and cannot dampen properly. The 2200LL-9 restores correct shock travel and dampening for a controlled, comfortable ride on a lowered F-150.

Does the MaxTrac 2200LL-9 warranty cover installation on lifted or modified trucks?
MaxTrac voids the warranty on all suspension parts installed on vehicles running wheels wider than 9 inches or with less than 4.5 inches of backspacing. Standard truck wheel sizing is typically within the covered range. Confirm your wheel specs before installation.

Is the MaxTrac 2200LL-9 covered by the Magnuson-Moss Warranty Act?
Under the Magnuson-Moss Warranty Act, your vehicle manufacturer cannot void your factory warranty solely because you installed an aftermarket shock absorber, unless they can demonstrate that the specific aftermarket part caused a specific failure. Aftermarket suspension parts are legal modifications and do not automatically void powertrain or other vehicle warranties.

Install Instructions

Safely lift the rear of the F-150 and support the frame on jack stands. Support the rear axle with a floor jack to prevent the axle from dropping during shock removal. Unbolt the upper and lower factory shock mounting hardware. Remove the stock shock. Slide the included 0.4375-inch steel sleeves onto the 2200LL-9 bushing ends as required by the mount configuration. Install the 2200LL-9 with the piston rod shaft oriented upward toward the top of the mount. Torque all fasteners to Ford factory specifications. The 2200LL-9 must be installed with the shaft up, do not invert the shock. Install both rear shocks before lowering the vehicle from the stands.
