Nitrous Express 96-04 Ford Mustang Cobra/Mach 1 (4 Valve) EFI Nitrous Plate Conversion

Add up to 300 horsepower to your 4 Valve Mustang at the flip of a switch

The Nitrous Express NX950 4 Valve EFI Plate Conversion is a complete wet plate nitrous system engineered specifically for the 1996 to 2004 Ford Mustang Cobra and 2003 to 2004 Mach 1. A billet aluminum, spray barless nitrous plate slips between the throttle body and intake manifold for clean, attractive installation, while Lightning Series billet aluminum and carbon fiber solenoids deliver the flow and reliability you need. With jetting included from 50 to 300 horsepower at the rear wheels, this system scales from street manners to full track damage with a jet change.

Why Cobra and Mach 1 owners choose the NX 4 Valve Plate System

• Spray barless billet aluminum throttle body plate, CNC machined and anodized black, no spray bars to sag or disrupt airflow
• Lightning Series nitrous and fuel solenoids with CNC billet bodies and carbon fiber cans for performance and weight savings
• Schrader valve fuel rail adapter for fast, no cut fuel system tie in
• TPS wide open throttle switch only allows activation at full throttle
• Master arming switch, relay, and relay harness included for safe, clean wiring
• 4AN nitrous feed line, stainless braided solenoid to plate lines
• Jetting included for 50, 75, 100, 150, 200, 250, and 300 horsepower
• Includes all hardware needed to complete installation, no extra trips to the parts store

What you should know before you spray

The NX EFI Plate System is designed to operate with the stock fuel pump and no timing retard up to the 100 horsepower setting. Above 100 horsepower, an upgraded high flow fuel pump rated at 250 LPH or higher is required, along with high octane race fuel and appropriate timing retard to prevent detonation. At 200 horsepower and above, plan on increased strength internal engine components and high performance head gaskets depending on your engine combination, compression, and fuel quality. This is a wet plate system, please follow the included Nitrous Express instruction sheet to the letter for safe operation.

Fitment

This Nitrous Express NX950 4 Valve EFI Plate System fits the following Ford 4.6L 4V chassis:

• 1996 to 2001 Ford Mustang SVT Cobra, 4.6L 4 Valve
• 2003 to 2004 Ford Mustang SVT Cobra, 4.6L 4 Valve supercharged, plate mounts between throttle body and supercharger inlet
• 2003 to 2004 Ford Mustang Mach 1, 4.6L 4 Valve

Always verify your engine, intake configuration, and bottle size against the manufacturer listing before ordering. Note that NX nitrous bottles ship empty and must be filled at an NX accredited filling station before use.

Specifications

• Part number: NX950
• System type: Wet EFI plate, spray barless
• Plate: Billet aluminum, CNC machined, black anodized
• Solenoids: Lightning Series billet aluminum with carbon fiber cans, nitrous and fuel
• Jetting range: 50 to 300 horsepower
• Bottle valve: Billet aluminum Lightning 45 with bottle option
• Nitrous feed line: 4AN, length per current NX spec
• Activation: TPS wide open throttle switch with master arming switch
• Compatibility: 1996 to 2004 Ford Mustang Cobra and 2003 to 2004 Mach 1, 4.6L 4 Valve

What is in the box

• Billet aluminum 4 Valve nitrous plate
• Lightning Series nitrous and fuel solenoids
• Stainless braided solenoid to plate lines
• 4AN nitrous feed line
• Schrader valve fuel rail adapter
• TPS wide open throttle switch
• Master arming switch, relay, and relay harness
• Jetting for 50, 75, 100, 150, 200, 250, and 300 horsepower
• NX red liquid thread sealer and complete hardware kit
• Bottle and bottle valve if ordered with the bottle option

Installation Instructions

1. Disconnect the negative battery cable and select the starting horsepower jet, installing the matching N2O and fuel jets in the plate using a back up wrench at all times.
2. Remove the upper intake manifold, clean both mating surfaces, and place the nitrous plate with new gaskets between the throttle body and intake with the fuel and nitrous fittings facing the front of the vehicle. Torque the intake bolts to factory spec.
3. Mount the nitrous bottle in the trunk or outside the passenger compartment using the supplied brackets, oriented per the NX bottle position diagram so the siphon tube stays covered.
4. Route the 4AN nitrous feed line from the bottle to the engine compartment along the factory fuel lines, keeping clearance from heat, moving parts, and electrical leads, and secure with zip ties.
5. Mount the solenoids near the plate so the supply lines have slack, install the inlet and outlet fittings using only the red NX liquid thread sealer, then connect the blue N2O and red fuel lines from solenoids to plate.
6. Locate the Schrader fuel test port on the fuel rail, install the supplied adapter, and connect the red fuel line to the inlet side of the fuel solenoid.
7. Mount the master arming switch within easy reach of the driver, install the TPS wide open throttle switch, and wire the relay following the NX schematic for power, ground, solenoid power, and activation paths.
8. With the bottle still closed, test both solenoids by arming the system and triggering the WOT switch, listening for both solenoids to click cleanly. Then open the bottle, leak check every fitting, and verify fuel pump and ECU configuration before any wide open throttle test pull.
