Weld Racing Laguna Drag
Weld 20x10 Laguna 6 Drag 6x135 ET38 BS 6.99 Gloss Black 87.1
Click to zoom in

Weld 20x10 Laguna 6 Drag 6x135 ET38 BS 6.99 Gloss Black 87.1

Weld
WELS15900089P38
190300624102
Wheels - Cast
3 Units In Stock - Ships Next Business Day
$ 640.00
$ 640.00

SKU: S15900089P38 | UPC: 190300624102

Weld 20x10 Laguna 6 Drag 6x135 ET38 BS 6.99 Gloss Black 87.1 for 2004-2024 Ford F-150

The Weld Laguna 6 Drag wheel measures 20 inches by 10 inches with a gloss black finish built for drag strip performance on Ford F-150 trucks. It uses a 6x135 bolt pattern ET38 offset and 87.1mm hub bore for direct fitment on 2004-2024 F-150 models plus Expedition and Navigator. This cast aluminum wheel reduces rotational mass to improve acceleration and handling during launches.

Key Features

  • Dimensions: 20x10 inch size with +38mm offset and 6.99 inch backspace positions tire perfectly for wide drag setups without rubbing
  • Bolt Pattern: 6x135mm matches Ford F-Series trucks for secure bolting and no adapters needed
  • Hub Bore: 87.1mm hub-centric design centers wheel precisely to minimize vibrations and ensure smooth rotation
  • Finish: Gloss black coating withstands track heat road salt and brake dust for long-lasting appearance
  • Construction: One-piece cast aluminum at 31.4 lbs sheds weight versus steel wheels to boost quarter-mile times

Product Notes

  • Verify tire size and suspension clearance before install especially with lowered setups
  • Wipe clean with soap and water dry thoroughly after track use to preserve finish
  • Single wheel ships via UPS Ground individual carton protects during transit

Installation Notes

  • Professional installation recommended.
  • Torque lug nuts to 150 ft-lbs in star pattern after 50 miles
  • Hub-centric fit works with OEM conical seat lug nuts no spacers required

This Part Fits

Year Make Model Submodel
2004-2024 Ford F-150 All
2007-2024 Ford Expedition All
2007-2024 Lincoln Navigator All
2009-2014 Ford F-150 Raptor All

Why Choose Weld Racing?

  • Drag racing leader since 1967 with wheels on winning cars across NHRA classes
  • Cast wheels balance strength and low weight for real-world track demands
  • Precision machining ensures concentricity for straight-line stability

Frequently Asked Questions

  • Q: Will this wheel fit my 2015 Ford F-150?
    A: Yes 6x135 bolt pattern and 87.1 hub bore provide direct bolt-on fit for all 2004-2024 F-150 trims including Raptor with proper tire clearance.
  • Q: Is the wheel hub-centric and what material?
    A: Yes 87.1mm bore centers on Ford hubs. High-strength cast aluminum construction keeps weight at 31.4 lbs for performance gains.
  • Q: What warranty coverage and install tips?
    A: Lifetime structural warranty against manufacturing defects. Install with hub-centric rings if needed torque to spec and recheck after break-in.

Shipping & Handling

  • Method: UPS Ground
  • Availability: In stock - ships same or next business day
  • Packaging: Box measures 22x22x13 inches
  • Weight: 31.4 lbs per wheel 37 lbs boxed
